Overview
The Carlo Gavazzi IA08BSF20PO inductive proximity sensor is designed for demanding industrial automation environments. As part of Carlo Gavazzi’s proven IA series, this M8 stainless steel sensor detects ferrous and non-ferrous metallic objects with repeatability and stability. The sensor combines a compact form factor with robust electrical protection, making it suitable for motion control, machine positioning, and assembly line automation.
Key Features
- M8 Stainless Steel Housing: M8 stainless steel housing with a 2m PVC cable for corrosion resistance and durability in harsh environments
- PNP Output with NO Contact: Output configurations standard to the Carlo Gavazzi type IA inductive proximity sensor include NPN/PNP transistor with both NO (normally open) and NC (normally closed)
- Compact Design: Short body option optimized for space-constrained installations
- IP67 Rating: Sealed against dust and immersion, suitable for washdown and wet environments
- 2m Pre-Terminated Cable: Ready-to-install connection with standard M8 plug
Technical Specifications
Exact specifications for the IA08BSF20PO are subject to verification with the manufacturer. General IA08 series parameters typically include:
- Supply voltage: 10–30 VDC
- Output current: up to 100 mA
- Switching frequency: ~2 kHz
- Operating temperature: −25°C to +80°C (−13°F to +176°F)
- Sensing range: 2 mm nominal
- IP protection class: IP67
- Housing material: Stainless steel M8
- Cable length: 2 m PVC
- Output type: PNP, NO (normally open)
Typical Applications
- Machine tool positioning and part detection
- Conveyor line speed monitoring and jam detection
- Cylinder position feedback in pneumatic and hydraulic systems
- Door, gate, and safety interlock status confirmation
- Assembly line component presence verification
- Food processing and packaging equipment control
- Automotive production line synchronization
Compatibility & Replacements
Compatible With
- PLC and motion controller analog/digital inputs supporting 10–30 VDC signals
- Industrial automation systems and machine control equipment
- Pneumatic and hydraulic valve position monitoring circuits
- Safety interlocks and interlock control modules
- Typical industrial fieldbus networks accepting standard transistor outputs
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The IA08BSF20PO is part of the Carlo Gavazzi IA08 family. Common similar models in the same series include IA08BSF20NO (NPN variant). Always confirm output type (PNP vs. NPN) and sensing range before substitution.
Works With
- Standard industrial PLC input modules (24 VDC logic compatible)
- Analog input cards accepting transistor switching signals
- Relay and solid-state switching circuits
- Control systems requiring discrete metal detection feedback
- Standard M8 socket connectors and mounting brackets (AMB series)
