Overview
The Bosch Rexroth R162211420 is a precision ball runner block designed for demanding linear motion and guidance applications. This KWD-015-SNS-C1-N-1 model combines high rigidity, repeatability, and low friction characteristics that make it essential for machine tools, automation systems, and industrial equipment requiring smooth, reliable linear travel. The block is compatible with all SNS/SNO ball guide rail systems from Bosch Rexroth.
Key Features
- Four-row ball configuration — minimizes friction and provides excellent dynamic characteristics in all loading directions
- Integrated all-round sealing — protects internal components against contaminants during operation
- Factory pre-lubricated — arrives with Dynalub 510 roller bearing grease for immediate installation and extended service intervals
- Standard accuracy (N class) — suitable for precision applications while maintaining cost efficiency
- Moderate preload (C1) — balances load capacity with low friction for general industrial use
- Slimline width design — fits confined spaces without sacrificing load-carrying capability
Technical Specifications
Size 15 format with slimline width, normal length, and standard height. The runner block body is manufactured from unalloyed steel (CS). Preload class C1 provides moderate preload, and accuracy class N delivers standard precision. Overall length is 58.2 mm. The block includes lube fittings with metal threads on all sides and end-face fastening threads for flexible attachment options. It operates with Dynalub 510 roller bearing grease and straight lube connection.
Typical Applications
This ball runner block is ideal for:
- Machine tool tables and slides
- Industrial automation assemblies requiring precision linear motion
- High-rigidity systems where single-block-per-rail mounting is preferred
- Manufacturing equipment with moderate to high load requirements
- Packaging and material handling machinery with positional accuracy demands
Compatibility & Replacements
Compatible With
- Bosch Rexroth SNS ball guide rail systems (all sizes and accuracies within class)
- Bosch Rexroth SNO ball guide rail systems
- Systems requiring size 15 runner blocks with C1 preload and N accuracy
- Rail systems using standard Dynalub 510 roller bearing grease
Replaces / Drop-In Replacement For
The Bosch Rexroth R162211420 offers limitless interchangeability within accuracy class N across all Bosch Rexroth ball guide rail systems. Cross-reference equivalent models include R160516432, R160710432, R160513431, R160710431, R160516431, R160513432, R160510432, and R160510431.
Works With
- Bosch Rexroth Ball Rail Systems (B.RAIL product line)
- SNS and SNO rail mounting configurations
- Standard industrial linear motion assemblies and sub-systems
- Preventive maintenance programs requiring periodic re-lubrication
