Overview
The Bimba HD35-250 clevis bracket is an accessory mounting kit designed for pneumatic and hydraulic cylinder applications. This assembly includes the clevis bracket, mounting pin, and complete hardware set, providing a ready-to-install solution for end-of-rod mounting on compatible cylinder models. Engineered to Bimba’s quality standards, this component ensures reliable performance in industrial automation, fluid power systems, and pneumatic equipment installations.
Key Features
- Complete mounting kit with clevis bracket, pin, and hardware—no additional fasteners required
- Designed for MP2 clevis mounting on rod ends
- Guaranteed compatibility with DM1, DM2, and HD1-250 series cylinders
- Precision-manufactured to Bimba specifications for reliable, long-term performance
- New in box condition with original factory packaging
Technical Specifications
- Part Number: HD35-250
- Assembly Type: Clevis Bracket with Hardware Kit
- Bracket Style: MP2 (Mating/Mounting Plate 2)
- Pin Type: Included
- Compatible Cylinder Series: DM1, DM2, HD1-250
- Fastener Hardware: Complete set included
- Condition: New in Box
- Manufacturer: Bimba Manufacturing
Typical Applications
- Industrial automation equipment requiring end-of-rod cylinder mounting
- Pneumatic and hydraulic power press assemblies
- Machine tool positioning and clamping systems
- Production line actuator attachment and alignment
- Plant maintenance and equipment retrofit applications
- Control panel and machinery rebuilds using OEM components
Compatibility & Replacements
Compatible With
- Bimba DM1 series cylinders
- Bimba DM2 series cylinders
- Bimba HD1-250 series cylinders
- ISO 6431 and ISO 6432 cylinder standards
- Pneumatic and hydraulic power systems using standard clevis rod ends
Replaces / Drop-In Replacement For
- Original Bimba HD35-250 assemblies
- Equivalent OEM clevis bracket kits for DM and HD series cylinders
- Field replacement for worn or damaged clevis mounting assemblies on compatible Bimba cylinders
Works With
- Bimba brand cylinders and actuators
- Standard pneumatic and hydraulic circuit designs
- Industrial mounting and alignment frameworks
- Equipment requiring rod-end pivot or hinge mounting
