Overview
The Bimba ARC-1 clevis rod is a double-wall design fastener engineered for mounting and aligning pneumatic cylinders with 4-inch bore configurations. Manufactured from stainless steel, this precision-machined component provides corrosion resistance and durability in demanding industrial environments. Designed to work seamlessly with Bimba pneumatic cylinders and alignment couplers, the ARC-1 eliminates side loads that can restrict cylinder operation and extends equipment lifespan.
Key Features
- Double-wall construction — reinforced design for enhanced load-bearing capability
- Stainless steel material — superior corrosion resistance for wet or chemical environments
- Precision machined — tight tolerances ensure accurate cylinder alignment
- ISO 9001 certified — manufactured to strict quality standards
- Complete hardware included — clevis pins, nuts, and mounting clips supplied
- Optimized for 4-inch bore cylinders — sized specifically for larger pneumatic applications
Technical Specifications
- Bore Size: 4 inches
- Material: Stainless Steel
- Design: Double-Wall Clevis Rod
- Weight: 0.38 lbs
- Certification: ISO 9001
- Finish: Stainless Steel (corrosion-resistant)
- Hardware Included: Clevis pin, nut, spring clips
- Manufacturer: Bimba (IMI Bimba)
Typical Applications
The Bimba ARC-1 is ideal for industrial automation and pneumatic control systems where cylinder mounting alignment is critical. Common applications include:
- Manufacturing equipment requiring precise cylinder positioning
- Material handling and conveyor systems
- Assembly line automation with pneumatic actuators
- Industrial machinery requiring robust clevis mounting
- Heavy-duty applications in wet, chemical, or corrosive environments due to stainless steel construction
Compatibility & Replacements
Compatible With
- Bimba pneumatic cylinders with 4-inch bore (B4″)
- Bimba alignment couplers and mounting systems
- Standard industrial pneumatic cylinder mounts
- Clevis pin assemblies (included hardware)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The ARC-1 is specifically designed for 4-inch bore applications; other clevis rod models (such as ARC-2 for 3.25-4 inch bore range) may have different specifications.
Works With
- Bimba Double-Wall cylinder series
- Bimba pneumatic control systems
- Standard industrial pneumatic automation platforms
- ISO 4401 and ISO 1219 compliant hydraulic/pneumatic layouts
