Overview
The Banner SM312DMHSM5VQD is a miniature photoelectric sensor engineered for presence and absence detection in industrial automation and machine control applications. Operating on 5VDC, this self-contained diffuse-mode sensor combines compact form factor with robust performance. The SM312 series delivers consistent sensing across registration, conveyor, and packaging applications where space and reliability are critical.
Key Features
- Compact 18 mm mini-beam design fits tight mounting spaces
- Diffuse sensing mode for flexible object detection without reflectors
- 5VDC operation ideal for low-voltage automation circuits
- Signal strength output indicator for alignment and diagnostics
- Rugged epoxy-encapsulated housing with acrylic lens and stainless steel hardware
- Quick-disconnect M12 connector for tool-free cable connection
Technical Specifications
- Supply Voltage: 5VDC
- Power Consumption: Nominal current draw (verify with system)
- Sensing Mode: Diffuse (no reflector required)
- Housing Material: Epoxy-encapsulated reinforced PBT thermoplastic
- Lens Type: Acrylic, 18 mm threaded barrel
- Connector: M12 Quick Disconnect (QD)
- Weight: 0.17 lbs (77 grams)
- Operating Temperature Range: Consult datasheet for limits
- Environmental Sealing: O-ring sealed, totally encapsulated
- Output Configuration: Selectable light-operate or dark-operate
Typical Applications
- Registration mark detection on web materials and labels
- Carton and package detection on conveyor lines
- Clear film web break detection
- Baggage handling and sorting systems
- Bottle and container position verification
- Parts counting and presence verification in assembly automation
Compatibility & Replacements
Compatible With
- 5VDC automation control circuits and PLC input modules
- Low-voltage DC conveyor and machinery control systems
- Standard M12 QD-equipped industrial controllers
- Vision inspection and part feeding automation
Replaces / Drop-In Replacement For
- Legacy Banner SM312 models with equivalent 5VDC configurations
- Standard 18 mm barrel-type photoelectric sensors in diffuse mode
Works With
- M12 Quick Disconnect (QD) connectors and male cable assemblies
- Standard PLC analog and digital input modules accepting 5VDC sensors
- Industrial control systems using diffuse-mode photoelectric logic
- Banner sensor software and alignment tools
