Overview
The Banner MRB photoelectric control base is a rugged aluminum chassis designed for modular photoelectric sensor control and relay logic. This used component accepts standard Banner octal-base amplifier and relay modules, making it a flexible platform for light-sensing applications in manufacturing, material handling, and process automation. The MRB architecture supports discrete Light/Dark operation and integrates readily with legacy automation systems.
Key Features
- Dual Socket Design: One socket accepts photoelectric amplifier modules; the other accommodates relay or logic modules for flexible system configuration.
- Standard Octal Base: Compatible with Banner’s modular M-series and B-series amplifier and relay module family for easy reconfiguration and upgrades.
- Aluminum Construction: Durable, lightweight chassis suitable for panel mounting or standalone operation.
- Wide Input Range: Operates on 11–14 VAC or 12–18 VDC, fitting diverse plant electrical standards.
- Light/Dark Operation: Simple switching logic for detection of object presence, edge location, or contrast changes.
Technical Specifications
- Input Voltage: 11–14 VAC or 12–18 VDC
- Socket Configuration: Octal base (two sockets)
- Construction Material: Aluminum
- Module Type: Photoelectric amplifier & relay logic
- Operating Principle: Light/Dark detection
- Compatibility: Banner M-series & B-series modules
- Mounting: Panel or chassis mount
- Manufacturer: Banner Engineering
- Condition: Used, fully functional
Typical Applications
- Part presence detection in assembly lines and packaging equipment
- Edge detection and positioning in print and converting systems
- Contrast sensing for quality inspection and sorting
- Retrofit or spare component for existing Banner photoelectric systems
- Laboratory and test equipment setups requiring modular sensor logic
Compatibility & Replacements
Compatible With
- Banner M-series modulated amplifier modules
- Banner B-series photoelectric amplifier modules
- Banner relay and logic module family with octal-base form factor
- Standard 24 VDC and 115 VAC industrial control panels
- Discrete sensor heads with Banner connectors (PS2, PS3, PS4 series)
Replaces / Drop-In Replacement For
The Banner MRB control base is a direct replacement for legacy Banner photoelectric control systems using the same octal-base socket architecture. Verify specific module compatibility with your system integrator before ordering to ensure proper electrical and mechanical fit.
Works With
- Banner Engineering photoelectric sensor modules (modulated and non-modulated types)
- Discrete relay logic timing and sequencing modules
- Banner connector and cable assemblies for sensor wiring
- Standard DIN rail and panel-mounting hardware
- Legacy Banner control system architectures from the 1980s–2000s era
