Overview
The Balluff BTL5-A11-M1220-P-S32/US is a magnetostrictive linear position transducer designed for high-accuracy position monitoring in industrial automation and control applications. With a 1220 mm measuring stroke and analog 0–10 V output, this sensor delivers reliable position feedback for closed-loop control systems.
Key Features
- 1220 mm (48 in.) measuring stroke length
- 0–10 V analog output (MICROPULSE technology)
- 24 VDC operating supply voltage
- Rising/falling output selectable
- Standard profile housing (37 × 35 mm aluminum, anodized)
- Non-contact magnetostrictive measurement—no mechanical wear
- M16 quick-disconnect connector (S32)
- Operating temperature range –40 to +85 °C
Technical Specifications
Electrical: Supply voltage 20–28 VDC (24 VDC nominal); Output 0–10 V analog; Time constant ~10 ms
Measurement: Stroke length 1220 mm; Repeat accuracy ±5 µm typical; Operating temperature –40 to +85 °C
Housing: Profile aluminum (37 × 35 mm), anodized; IP67 with connector
Interface: 8-pin quick-disconnect metal connector (M16)
Typical Applications
- Position feedback for closed-loop control of hydraulic cylinders
- Motion monitoring on plastics and rubber manufacturing equipment
- Positioning control on packaging and automated assembly machinery
- Industrial hydraulic and pneumatic actuation systems
- Mobile and offroad equipment position sensing
Compatibility & Replacements
Compatible With
- Industrial PLC systems requiring 0–10 V analog input
- Proportional valve control systems
- Closed-loop servo and motion control applications
- Hydraulic and pneumatic actuation monitoring
- Standard DAQ and industrial automation controllers
Replaces / Drop-In Replacement For
This model is part of the Balluff BTL5-A11 series. For specific cross-references to competing transducers, verify compatibility with your system integrator before ordering.
Works With
- Analog input modules on Allen-Bradley, Siemens, Mitsubishi, and Omron PLCs
- Industrial DAQ systems with 0–10 V analog channels
- Proportional valve controllers and hydraulic systems
- SCADA software and HMI packages supporting 4–20 mA and 0–10 V signals
