Overview
The Superstrut A716-3/4 Cush-A-Clamp is a professional-grade cushioned pipe clamp from Thomas & Betts, ideal for securing fluid conductor lines in industrial and commercial applications. This 2-piece clamp accommodates 3/4 in OD tubing and features a molded cushion that absorbs vibration and shock from pressure surges, reducing wear on pipes and downstream components.
Key Features
- 2-piece design with integrated elastomer cushion for shock absorption
- Gold-galvanized steel construction for corrosion resistance
- Accepts 3/4 in outside diameter pipe, tube, or hose
- Channel-mount or beam-mount compatible for flexible installation
- Temperature range: -40°F to 300°F
- Sold in protective box packaging (16 units per box)
Technical Specifications
- Outside Diameter Capacity: 3/4 in
- Clamp Type: 2-Piece Cushioned
- Material: Steel, gold galvanized
- Gauge: 14 ga
- Length: 2.351 in
- Width: 1.2 in
- Operating Temperature: -40°F to 300°F
- Series: 700 (Superstrut A716)
- Mounting: Channel or beam compatible
- Application: Pipe, tube, and hose support
- Quantity per Box: 16 units
Typical Applications
The Superstrut A716-3/4 Cush-A-Clamp is widely used in:
- HVAC systems for refrigerant and chilled water lines
- Compressed air distribution networks
- Hydraulic and pneumatic systems
- Industrial process piping
- OEM equipment and machinery where vibration isolation is critical
- Building services and mechanical contracting
Compatibility & Replacements
Compatible With
- Standard 3/4 in OD copper, steel, and plastic tubes
- Industrial piping systems operating at -40°F to 300°F
- Channel-type and beam-type support systems
- Superstrut channel framing systems
- Mechanical equipment requiring vibration damping
Replaces / Drop-In Replacement For
- American Electric P-716-3/4 (alternate part numbering)
- Legacy Superstrut A716-3/4 variants
Works With
- Superstrut channel nuts and fasteners
- Standard U-bolts and mounting brackets
- Beam clamp adapters and rod hangers
- Industrial support structures and framework
