Overview
The Allen-Bradley 800H-NP34 /X enclosure cover is a heavy-duty component from Rockwell Automation’s Bulletin 800H control station family. Specifically engineered for 30mm selector switch stations, this double lever cover protects electrical controls while providing seamless operation across industrial facilities. The /X designation indicates Series X generation equipment, incorporating years of design refinement for maximum reliability.
Key Features
- IP66 Protection Rating: Resists dust, water, and environmental contaminants in challenging outdoor and wet locations
- Impact-Resistant Material: Constructed from high-quality plastic engineered for durability in harsh industrial conditions
- 30mm Selector Switch Compatibility: Precisely engineered fit for 30mm selector switch operators
- Double Lever Design: Ergonomic control actuation for reliable field operation
- NEMA 7/9 Type Rating: Suitable for hazardous location Class I Division 1 and 2 applications
- Field-Installable: Standard mounting hardware provided for quick enclosure assembly
Technical Specifications
- Enclosure Type: Selector Switch Cover, 1 Gang, 1 Hole
- Operator Size: 30mm (1.18 inches)
- Lever Style: Double Lever
- Protection Rating: IP66
- NEMA/IEC Rating: Type 7, Type 9
- Hazardous Location Class: Class I, Division 1 & 2
- Material: Impact-resistant polymer
- Series: X (Latest generation)
- Installation: Field-mount with provided hardware
Typical Applications
- Petrochemical and chemical processing plants with hazardous atmospheres
- Oil and gas production and drilling control stations
- Pharmaceutical manufacturing environments requiring washdown resistance
- Food and beverage processing facilities
- Mining operations where dust protection is critical
- Offshore and marine installations exposed to corrosive salt spray
- Agricultural equipment control panels
Compatibility & Replacements
The 800H-NP34 /X is directly compatible with all Allen-Bradley Bulletin 800H 30mm selector switch stations. Common related enclosure covers in the 800H family include the 800H-NP30 (1-hole standard cover) and other NP-series variants for different switch sizes and configurations. When replacing covers on legacy systems, verify that the operator size matches—this model fits 30mm devices only. For systems requiring different configurations or older 800T-series equipment, consult your Rockwell Automation distributor to confirm compatibility.
