Overview
The Allen-Bradley 3811097603 is a digital display board and cover assembly designed for use with industrial drive systems and automation equipment. This component provides a compact operator interface for monitoring and controlling drive parameters in manufacturing and process control environments. Originally discontinued by the manufacturer, this component remains available as a used surplus part for maintenance, repair, and retrofit applications where original-specification interfaces are required.
Key Features
- 4-Digit Numeric Display Block – Clear alphanumeric readout for parameter and status display
- 8 Pushbutton Controls – Tactile input interface for menu navigation and parameter adjustment
- Black Dial Face – High-contrast display panel for visibility in industrial environments
- Screw Terminal Connections – 15 screw terminals for reliable wired connections
- RJ Port Connectivity – Supports standard interface connector options for drive integration
- Compact Design – Space-efficient form factor suitable for retrofit installations
Technical Specifications
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Part Number | 3811097603 (38110-976-03) |
| Product Type | Digital Display Board & Cover Assembly |
| Display Type | 4-Digit Numeric Block |
| Display Color | Black Dial |
| Pushbutton Controls | 8 buttons |
| Screw Terminals | 15 connection points |
| Connector Type | RJ Port / Screw Terminal Mix |
| Weight | 0.12 lbs (54 grams) |
| Status | Discontinued by Manufacturer |
| Condition | Used |
Typical Applications
- PowerFlex drive parameter interface and diagnostics
- Industrial drive control panels and operator stations
- Motor control and speed adjustment systems
- Drive commissioning, troubleshooting, and maintenance
- Legacy automation system retrofits and repairs
- Equipment upgrades requiring original-specification interfaces
Compatibility & Replacements
The Allen-Bradley 3811097603 is a legacy component designed for integration with PowerFlex drive systems and earlier-generation Allen-Bradley operator interface architectures. Verify voltage, phase, and horsepower requirements before installation, as this component’s configuration may depend on the specific drive model and system design. Modern alternatives may include PowerFlex graphic display modules or contemporary HMI solutions, but original-specification replacements like this unit are often required for equipment compatibility in established control systems.
This is a used surplus part. Original factory warranty does not apply; however, reputable distributors typically provide their own warranty coverage. Always confirm pin-out compatibility and connector specifications with your system documentation before ordering.
