Overview
The Allen-Bradley 198-H4 support bracket is the original equipment manufacturer (OEM) bracket for the 198-H4 rotary operating mechanism. Designed to provide structural support and maintain precise alignment, this bracket ensures stable operation of HMCP rotary mechanisms in industrial electrical applications.
Key Features
- OEM support bracket for Allen-Bradley 198-H4 mechanism
- Designed for HMCP frame circuit breakers and starters
- Provides structural stability and alignment support
- NEMA 1/3/3R/4/4X/12 compatible applications
- Factory-engineered for reliable performance
- Direct fit for 198-H4 rotary operating mechanism assemblies
Technical Specifications
- Manufacturer: Rockwell Automation / Allen-Bradley
- Series: 198
- Model: 198-H4
- Type: Support Bracket
- Application: HMCP Rotary Operating Mechanism
- Mechanism Type: Rotary Handle/Operation
- Enclosure Rating: NEMA 1/3/3R/4/4X/12
- Compatible Equipment: Circuit Breakers and Starters
- Condition: New in Box
- Compatibility: 198-H4 /A mechanism assemblies
Typical Applications
- HMCP circuit breaker enclosure mounting and support
- Industrial electrical equipment control
- Motor starter mechanism alignment
- Disconnect switch installations requiring rotary operation
- Utility and industrial power distribution systems
Compatibility & Replacements
The Allen-Bradley 198-H4 support bracket is specifically designed for the 198-H4 /A rotary operating mechanism. This bracket is part of the Allen-Bradley 198 series family, which includes other mechanism models (198-H1, 198-H2, 198-H3) for different amperage and frame ratings. Verify mechanism model before ordering to ensure proper fit. OEM parts from Rockwell Automation offer exact compatibility and meet original performance specifications.
