Overview
The Allen-Bradley 100S-C23EJ23C is a compact IEC safety contactor designed for industrial machinery control and hazard isolation. This 23 amp unit features a 24VDC electronic coil with integrated diode and mechanically linked mirror-contact architecture, ensuring reliable detection of main pole position for safety-critical feedback circuits. Compliant with IEC/EN 60947 standards and available for immediate shipment.
Key Features
- Mirror contact technology—main pole status continuously monitored for safe motion feedback
- Electronic coil with diode—24VDC supply; eliminates external snubber circuits
- 3-pole, 2NO + 3NC auxiliary contacts—meets modern safety circuit requirements
- IP2X enclosure rating—corrosion and contamination protection
- DIN rail / panel mounting—flexible installation in standard automation enclosures
- UL/CSA, C-TICK, CCC, KC certified—global compliance for machinery and safety applications
Technical Specifications
- Contact Rating: 23 A (690 V AC)
- Coil Voltage: 24 V DC (electronic, with diode)
- Contact Configuration: 3 NO power poles + 2 NO + 3 NC auxiliary
- Operating Temperature: −25 to +60 °C
- Enclosure Rating: IP2X
- Mounting: DIN rail or screw-mount panel
- Dimensions: 81 mm L × 45 mm W × 125.5 mm D
- Weight: ~1.06 lb
- Certifications: C-TICK, CCC, KC
- Series: 100S/104S IEC Safety Contactor
Typical Applications
- Hazardous machine brake and clutch control
- Emergency stop circuits requiring feedback validation
- Conveyors, presses, and material handling equipment
- Robotics and automated assembly lines
- NEMA/IEC motor and load control up to 750 A in dual-channel safety loops
