Overview
The Allen-Bradley C22206 is a specialized logic interface board providing 115VAC TTL Logic control for Allen-Bradley drive systems. This renewal part is engineered as a direct replacement component for the 1336-MOD-L3 platform and similar variable frequency drive architectures. Supplied new in box, it ensures compatibility with legacy and active drive installations.
Key Features
- 115VAC TTL Logic interface compatibility
- Direct replacement for 1336-MOD-L3 systems
- New-condition renewal component
- Industrial-grade logic board design
- Proven reliability in drive control applications
Technical Specifications
- Part Number: C22206
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Component Type: TTL Logic Interface Board
- Input Voltage: 115VAC
- Interface Type: TTL Logic
- Compatible Drive: 1336-MOD-L3
- Condition: New in Box
- Application: Variable Frequency Drive Control
Typical Applications
- AC motor drive TTL logic control and sequencing
- Drive signal conditioning and interface
- Legacy Allen-Bradley 1336-MOD-L3 system upgrades and maintenance
- Industrial automation and motion control systems requiring TTL-level drive communication
Compatibility & Replacements
The C22206 renewal part is specifically designed for direct installation in Allen-Bradley 1336-MOD-L3 variable frequency drives. When replacing aging or failed logic interface boards in active drive systems, this component provides identical form-fit-function compatibility. For system integration questions or alternative part numbers, consult the original drive documentation or contact our applications team.
