Allen Bradley AB ArmorPoint DeviceNet Network Adapter 1738-ADN12 /A

The Allen-Bradley 1738-ADN12 is an ArmorPoint DeviceNet Network Adapter designed to facilitate seamless integration of distributed I/O modules into DeviceNet networks.

Key Features

• DeviceNet Communication: Ensures reliable data exchange between connected I/O modules and the central control system.
• M12 Quick-Disconnect Terminations: Simplifies installation and maintenance with secure and efficient connections.
• Support for Multiple I/O Modules: Accommodates up to 63 ArmorPoint I/O modules on a single DeviceNet node, providing scalability for various applications.
• High I/O Point Capacity: Supports a maximum of 252 I/O points, enabling extensive system configurations.
• Wide Input Voltage Range: Operates within a 10-28.8V DC input voltage range, offering flexibility in power supply options.
• Robust Power Handling: Handles field-side power requirements of 400 mA at 24V DC, with a maximum power consumption of 8.0W and power dissipation up to 2.8W at 28.8V DC.
• Inrush Current Management: Manages inrush currents up to 6A for 10 milliseconds, ensuring system stability during power-up.
• Durable Construction: Features a sealed IP67-rated housing, eliminating the need for additional enclosures and providing protection against dust and water ingress.

Technical Specifications

• Communication Protocol: DeviceNet
• Termination Type: M12 Quick-Disconnect
• Input Voltage Range: 10-28.8V DC
• Field Side Power Requirements: 400 mA at 24V DC
• Power Consumption: 8.0W at 24V DC
• Power Dissipation: 2.8W at 28.8V DC
• Inrush Current: 6A for 10 milliseconds
• Operating Temperature Range: -20 to 60°C (-4 to 140°F)
• Enclosure Rating: IP67

The 1738-ADN12 adapter is engineered to provide a reliable and efficient solution for integrating distributed I/O modules into DeviceNet networks, making it suitable for a wide range of industrial automation applications.
