Overview
The Allen-Bradley 800F-N3R is a 22mm integrated red LED lamp module engineered for visual indication in industrial control systems. This module operates at 24V AC/DC and features a front-mounted latch design for secure installation in standard 22mm operator stations. The 800F-N3R delivers bright, energy-efficient LED illumination for status signaling, making it an essential component for motor control panels, machine safety systems, and industrial automation applications.
Key Features
- Integrated red LED technology for long-lasting, energy-efficient illumination
- Dual voltage operation: 24V AC/DC compatible with most industrial control systems
- 22mm compact form factor fits standard operator station cutouts
- Front latch-mount design ensures secure placement and easy serviceability
- Screw terminal connections for reliable electrical contact
- International certifications: CE, CCC, KC, UL 508, CSA, RoHS compliant
Technical Specifications
- Part Number: 800F-N3R
- Manufacturer: Allen-Bradley / Rockwell Automation
- Product Type: 22mm LED Module (Integrated Lamp)
- Lamp Type: LED (Red)
- Voltage Rating: 24V AC/DC
- Mounting Type: Front Latch Mount
- Size/Diameter: 22 mm
- Terminal Type: Screw
- Color: Red
- Series: 800F Push Button Family
- UPC: 662468119924
- Standards: EN 60947-1, EN 60947-5-1, IEC 60947-1, ISO 13850, NEMA ICS-5
- Lifecycle Status: Active
Typical Applications
The 800F-N3R red LED module is widely used in:
- Industrial motor control panels for run/stop indication
- Machine safety systems and emergency halt signaling
- PLC-based automation and process monitoring
- Fault and alarm notification in manufacturing equipment
- Status indicators in food & beverage, pharmaceutical, and assembly line controls
- Integration with Allen-Bradley 800F push button stations and operator interfaces
Compatibility & Replacements
Compatible With
- Allen-Bradley 800F push button and operator station family (22mm cutout)
- Industrial control panels with 24V AC/DC supply voltage
- PLC input/output systems requiring visual feedback modules
- Motor control centers and safety-rated control cabinets
- Rockwell Automation control architectures
Replaces / Drop-In Replacement For
- Older Allen-Bradley 800F incandescent lamp modules (backward-compatible form factor)
- Direct equivalent for OEM applications requiring 800F-N3R specification
Works With
- Allen-Bradley 800F series push buttons and selector switches
- 24V DC industrial control power supplies
- Standard 22mm operator station enclosures (IEC 60947 compliant)
- Motor starter and contactor control circuits
- Any PLC or controller with 24V LED indicator output capability
