Overview
The Allen-Bradley 700-HAX2A1 is a tube base general purpose relay manufactured by Rockwell Automation. This DPDT (double pole double throw) relay operates at 120V AC 50/60 Hz and features 8-pin construction for compatibility with standard socket installations. The 700-HAX2A1 offers reliable switching performance with bifurcated gold-plated contacts rated at 6 amps, making it suitable for a wide range of industrial control and automation applications including machine tools, pulp and paper, and transportation equipment.
Key Features
- DPDT configuration (2 changeover contacts) for flexible switching logic
- 6-amp bifurcated contacts with gold plating for enhanced reliability and reduced arcing
- 8-pin tube base design for use with standard relay sockets
- 120V AC 50/60 Hz coil voltage for North American industrial applications
- cULus listed and CSA certified for North American electrical standards
- Lower power consumption and extended contact life compared to legacy relay designs
Technical Specifications
- Contact Configuration: DPDT (2 changeover contacts)
- Coil Voltage: 120V AC 50/60 Hz
- Maximum Switching Current: 6 A
- Contact Material: Bifurcated with gold plating
- Pin Configuration: 8-pin tube base
- Certifications: cULus (File No. E3125), CSA C22.2 No. 14, EN 61810-1
- Standards Compliance: UL508, IEC 60947-5-1
Typical Applications
- Machine tool control systems and automation
- Pulp and paper processing equipment
- Transportation industry electrical controls
- General industrial switching and control circuits
- OEM equipment requiring reliable relay switching
- Panel-mounted control systems using tube base relay sockets
Compatibility & Replacements
Compatible With
- 700-HN tube base relay sockets (8-pin configuration)
- 700-HA series general purpose relay family
- Standard industrial relay control panels
- Legacy machine tool control systems
- Maintenance and replacement programs for existing installations
Replaces / Drop-In Replacement For
- Other 8-pin DPDT 120V AC tube base relays requiring 6A switching capacity
- Compatible as a direct replacement within 700-HA relay families with matching specifications
Works With
- 700-HN100, 700-HN101, 700-HN125, 700-HN126 tube base sockets
- Standard DIN rail mounting systems with appropriate socket adapters
- Industrial control panels and enclosures utilizing tube base relay architecture
- Manual override and push-to-test accessories compatible with 700-HA series
