Overview
The Allen-Bradley 700-CF310A is a robust 4-pole industrial control relay that meets IEC 60947-5-1 standards. It features 3 normally open (NO) and 1 normally closed (NC) contact configuration with 4 fixed contacts. This versatile component is engineered for reliable switching in industrial automation, control panels, and process control applications where dependable relay operation is critical.
Key Features
- Contact Configuration: 3 normally open (NO) contacts and 1 normally closed (NC) contact for versatile control options
- Coil Voltage: 120V AC, ensuring compatibility with standard industrial power sources
- Current Rating: Supports a maximum load of 10A at 240V AC, suitable for various electrical loads in industrial environments
- Mechanical Reliability: Offers a mechanical lifespan of over 10 million operations, ensuring long-term reliability and reduced maintenance costs
- Terminal Style: Screw terminals, with capability for top or side mounted auxiliary contact blocks
- IEC Compliance: Conforms to EN/IEC 60947-1, -5-1 standards
Technical Specifications
- Poles: 4 (4P)
- Contact Configuration: 3NO / 1NC
- Coil Voltage: 120V AC
- Maximum Current Rating: 10A @ 240V AC
- Terminal Type: Screw terminals
- Mounting: Panel mount
- Mechanical Life: >10 million cycles
- IEC Standard: IEC 60947-5-1
- Certifications: cULus Listed (File No. E14840), CSA C22.2 No. 14, CE Marked, UL 508
- RoHS Compliant: EU Directive 2002/95/EC
Typical Applications
- Industrial Automation: Ideal for controlling machinery and processes in manufacturing facilities, providing reliable switching capabilities
- Control Panels: Perfect for use in control panels and automation systems, enhancing operational workflows and efficiency
- Process Control: Suitable for use in various environments, including factories, assembly lines, and process control applications
- Equipment Interlocking: Multi-contact design supports complex logic switching and safety interlocking circuits
Compatibility & Replacements
Compatible With
- Allen-Bradley PLCs and HMIs within the Rockwell Automation ecosystem
- Industrial control panel assemblies
- 24V, 120V, and 240V AC power distribution systems
- Standard DIN-rail and panel-mount enclosures
Replaces / Drop-In Replacement For
- Other 700 Series 4-pole, 10A relay equivalents with identical contact/coil configuration
- Verify compatibility with your system integrator before ordering to ensure proper voltage and contact configuration match
Works With
- Rockwell Automation control systems and RSLogix programming environments
- Standard industrial PLC networks and field devices
- Relay sockets and auxiliary contact modules (700-HN series compatible)
- IEC 60947-5-1 compliant automation architectures
