Overview
The Allen-Bradley 5094-OB16 is a 16-point digital sourcing output module engineered for the Flex 5000 distributed I/O system. Manufactured as part of the Allen-Bradley Flex 5000 series, the 5094-OB16 delivers reliable control outputs for industrial automation applications. The module includes configuration with Studio 5000 Logix Designer application, enabling seamless integration with Logix 5000 control systems. This chassis-mounted module provides compact, space-saving I/O distribution across remote locations on your production floor.
Key Features
- 16 sourcing I/O channels for making connections
- Built-in diagnostics: open load detection, output short-circuit protection, overload protection, temperature protection, and reverse voltage protection
- Status monitoring via indicator lights—red and green module/SA power status, plus 16 individual I/O status indicators
- Requires 24 Volts DC power source connection through left SA +/– terminals
- Supports removal and insertion under power (RIUP)
- FLEX 5000 platform features 1 Gb EtherNet/IP connectivity with support for DLR, Star, Linear, and PRP topologies
