Overview
The Allen-Bradley 500L-TOD92 is a NEMA-rated lighting contactor designed for reliable switching of incandescent filament, fluorescent, mercury arc lamps, and capacitor loads. This electrically held contactor features a size 00 frame rated for 10A non-motor and resistive heating loads, with a 115-120V 60Hz coil voltage. The open-style enclosure and two-pole configuration make it ideal for commercial and industrial lighting control applications where dependable performance and long service life are required.
Key Features
- NEMA Size 00 — compact footprint suitable for space-constrained installations
- 10A rated capacity — handles non-motor resistive heating, ballast, and discharge lighting loads
- 115-120V 60Hz coil — standard North American control voltage
- Two-pole design — switches both phases in three-phase systems
- Electrically held — maintains position without mechanical latching when de-energized momentarily
- Open-style enclosure — allows easy access for inspection and maintenance
Technical Specifications
- Ampere Rating: 5A Tungsten Lamp / 10A Non-Motor, Resistive Heating, Ballast, Discharge Loads
- Coil Voltage: 115-120V 60Hz
- Frame Size: NEMA Size 00
- Pole Configuration: 2 Power Poles
- Enclosure Type: Open
- Load Type: Incandescent, Fluorescent, Mercury Arc Lamps; Capacitor Loads
- Product Family: Bulletin 500L Lighting Contactors
- Certifications: UL Listed (File No. E14843)
Typical Applications
- Commercial building lighting control and switching
- Industrial facility illumination systems
- Ballast and discharge lamp circuits in lighting panels
- Incandescent and fluorescent fixture switching
- Capacitor load switching in lighting networks
- Legacy lighting control system retrofits and replacements
Compatibility & Replacements
Compatible With
- Allen-Bradley Lighting Control systems and panels
- NEMA standard three-phase electrical systems
- Standard 115-120V 60Hz control circuits
- Incandescent, fluorescent, and mercury arc lamp assemblies
- Capacitor load switching applications
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering for existing installations requiring exact model substitution.
Works With
- Allen-Bradley timers, relays, and control devices
- Standard NEMA 1 and NEMA 4 enclosures
- UL-listed lighting control circuits and panels
- Manual and automatic lighting control schemes
