Overview
The Allen-Bradley 500-BOD92 /B is a NEMA Size 1 contactor from the Bulletin 500 series, designed for reliable motor control and starter applications in industrial automation. This two-pole unit operates on a 120V AC coil at 60Hz frequency, delivering dependable switching performance for machinery control, lighting circuits, and motor starters in manufacturing, process control, and facility automation environments.
Key Features
- NEMA Size 1 Classification: Compact, standardized form factor for open-type mounting in control panels and enclosures
- Two Main Poles: Dual contact sets provide flexible wiring configurations for single-phase and split-phase loads
- 120V AC Coil: Standard industrial coil voltage with 60Hz nominal frequency for North American installations
- 10 HP Maximum: Rated horsepower capacity suitable for small to medium industrial motors and equipment
- Open Type Design: Modular construction allows easy integration into custom control systems and panel assemblies
- Bulletin 500 Series: Allen-Bradley’s proven, industry-standard contactor line with broad compatibility and interchangeability options
Technical Specifications
| Part Number | 500-BOD92 /B |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Type | NEMA Size 1 Contactor |
| Series | Bulletin 500 |
| Coil Voltage | 120V AC |
| Frequency | 60 Hz |
| Poles | 2 |
| Horsepower Rating | 10 HP |
| Enclosure Type | Open Type |
| Mounting | DIN Rail or Panel Mount |
| Weight | Approximately 3.6 lbs |
| Condition | New in Box |
Typical Applications
The 500-BOD92 /B serves across diverse industrial automation and motor control roles:
- Machinery Control: Starter and control circuits for production equipment, conveyors, pumps, and compressors
- Lighting Control: Switchable contactor for facility lighting circuits and emergency systems
- Manufacturing Lines: Integration into PLC-based and hardwired control panels for sequential motor operation
- HVAC Systems: Motor switching for heating and cooling equipment in commercial buildings
- Retrofit Applications: Direct replacement for legacy Bulletin 500 contactors in existing control systems
Compatibility & Replacements
The 500-BOD92 /B is part of Allen-Bradley’s standardized Bulletin 500 contactor family, offering broad compatibility within the series. Related two-pole 120V models in the 500-BOD family include variants designated for different coil voltages and specifications. Engineers and technicians should verify coil voltage, pole count, and mounting requirements before substitution. Original equipment documentation or consultation with controls suppliers is recommended to confirm pin-to-pin compatibility with custom enclosures or legacy panel designs. This NEMA Size 1 unit integrates seamlessly with standard DIN rail and open-panel installations common in North American industrial facilities.
