Overview
The Allen-Bradley 194E-E100-NP is a 4th pole add-on module designed to expand the capabilities of existing 194E series load switches and disconnect systems. This 100A-rated additional pole module adds extra circuit control flexibility to industrial automation, power distribution, and machinery control systems. Built with high-quality materials and rated for harsh industrial environments, the 194E-E100-NP delivers dependable performance in demanding applications.
Key Features
- 100A current rating for robust industrial operation
- Stackable design allows multiple modules to be mounted on compatible base units
- High-quality copper construction ensures excellent conductivity and durability
- Withstands extreme temperatures and vibrations in industrial control systems
- CE, UL, and CSA certified for global safety compliance
- Drop-in configuration minimizes installation downtime
Technical Specifications
- Current Rating: 100A
- Voltage Rating: 600 VAC
- Series: 194E Load Switch
- Module Type: Additional Pole (4th Pole)
- Certification: CE, UL, CSA
- Construction: Copper contacts
- Mounting Style: Front mount with 194E base units
Typical Applications
- Industrial machinery and equipment control circuits
- Power distribution and load switching systems
- Multi-phase motor control and disconnect applications
- Factory automation and process control systems
- Emergency stop circuits requiring additional pole capacity
- System expansion without full unit replacement
Compatibility & Replacements
Compatible With
- Allen-Bradley 194E-series load switches and disconnect systems
- 194E base units rated 100A and higher
- Industrial control applications requiring additional pole expansion
- NEMA 3R/4/4X enclosed disconnect switch assemblies
Replaces / Drop-In Replacement For
- Original equipment 194E-E100-NP units (direct replacement)
- Legacy or damaged fourth pole modules on compatible 194E systems
- Verify compatibility with your system integrator before ordering to ensure base unit support
Works With
- 194E control and load switch platforms
- Industrial disconnect switch assemblies rated for 100A circuits
- Manual and motorized drive systems on compatible 194E bases
- Multi-pole control configurations in NEMA-rated enclosures
