Overview
The Allen-Bradley 1732ES-IB8XOB8 is an advanced ArmorBlock Guard I/O safety module engineered for robust machine-level automation and safety-critical applications. This hardened I/O module is suitable for on-machine use and can be mounted close to sensors and actuators to provide shorter cable runs for automotive, material handling, and high-speed packaging applications. The module provides PLd-rated, single channel safety inputs and PLe-rated, dual channel, safety inputs with safety outputs rated up to PLe.
Key Features
- Eight sinking inputs and eight solid state sourcing outputs for comprehensive control and monitoring capabilities
- IP67 rating ensures protection against dust and water ingress, making it suitable for harsh industrial environments
- Dual Ethernet ports for Linear and Device Level Ring topologies
- DC Micro (M12) termination type for secure connections and minimized installation time
- Configurable with a module-specific profile in Studio 5000 Logix Designer software
- 24 VDC operation with integrated safety diagnostics
Technical Specifications
The module delivers certified safety performance for demanding industrial environments:
- Input Type: 8 sinking inputs @ 24 VDC
- Output Type: 8 solid-state sourcing outputs
- Safety Rating: PLd single-channel, PLe dual-channel
- Communication: EtherNet/IP safety
- Connector Type: DC Micro (M12)
- Ingress Protection: IP67
- Operating temperature range: -4 to 131 degrees Fahrenheit
- Certifications: UL Listed, TUV General Safety, CE, Korean KC, ODVA
Typical Applications
These modules are suitable for use in welding applications and end-of-arm robot applications across automotive manufacturing, packaging machinery, material handling systems, and machine tool safety circuits. The ArmorBlock Guard architecture enables mounting directly on equipment frames or control panels in high-vibration environments.
Compatibility & Replacements
Compatible With
- GuardLogix, Compact GuardLogix, and Armor GuardLogix controllers
- EtherNet/IP networks with safety protocol support
- Linear and Device Level Ring topology configurations
- Rockwell Automation safety systems and SIL-rated machine architectures
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 1732ES-IB8XOB8 is the current production safety module in the ArmorBlock Guard line; older models may differ in safety certification levels or I/O configuration.
Works With
- Studio 5000 Logix Designer with GuardLogix add-on package
- EtherNet/IP communication protocol
- Rockwell Automation ThinManager HMI and visualization systems
- Third-party EtherNet/IP safety gateways and networks
