Overview
The Allen-Bradley 1494F-L1 Series A is a NEMA Type 12 door hardware kit engineered for secure latching on industrial disconnect switches. This kit is compatible with 1494F and 1494D disconnect switches and accommodates enclosure heights less than 30 inches. The right-hand configuration provides dual latching points—top and side—to ensure dependable door operation in demanding industrial environments.
Key Features
- NEMA Type 12 rated for sealed enclosures
- Includes handle, cam, defeater actuator lever, rollers, and shims
- Right-hand top and side latching configuration
- Designed for enclosures less than 30 inches in height
- Compatible with 1494F and 1494D disconnect switches
- Series A specification for legacy and new installations
Technical Specifications
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number: 1494F-L1
- Series: A
- Enclosure Type: NEMA Type 12
- Latch Configuration: Right-hand, top and side
- Max Enclosure Height: Less than 30 inches
- Compatibility: 1494F and 1494D disconnect switches
- Included Components: Handle, cam, defeater actuator lever, rollers, shims
- Standards: UL, CSA, CUL, KC
- Weight: Approximately 0.18–0.25 lbs (varies with sub-assembly)
Typical Applications
The 1494F-L1 door hardware kit is widely used in:
- Industrial control enclosures requiring secure door fastening
- Manufacturing facilities with 1494F or 1494D disconnect switches
- NEMA Type 12 enclosures subject to occasional moisture or coolant splash
- Machine control cabinets needing multi-point latching
- Retrofit or maintenance installations on existing enclosures
Compatibility & Replacements
The 1494F-L1 is part of the Allen-Bradley 1494 family of door hardware kits. Related kits in this series include the 1494F-L2 (top/bottom latching) and 1494F-L3 (side-only latching, typically used in combination with L2 for additional latching points). The kit integrates directly with 1494F and 1494D disconnect switches and is not interchangeable with 1494V-series hardware. Verify enclosure height and hand orientation before ordering to ensure proper fit and function.
