Overview
The Allen-Bradley 1494F-L1 door hardware kit delivers robust access control for industrial enclosures using 1494F and 1494D disconnect switches. NEMA 12 rated for solid performance in demanding environments, this kit provides top and side latching for secure, reliable door operation on enclosures under 30 inches in height.
Key Features
- NEMA Type 12 enclosure rating for corrosion and dust resistance
- Top and side latching mechanism for dual-point security
- Right-hand operation configuration
- Designed for enclosures less than 30 inches in height
- Compatible with 1494F and 1494D disconnect switches
- Complete kit includes handle, cam, defeater actuator lever, rollers, and shims
- CSA, CUL, KC, and UL certified
Technical Specifications
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number: 1494F-L1
- Kit Type: Door Hardware for Disconnect Switches
- Enclosure Rating: NEMA 12
- Latching Type: Top and Side
- Hand Operation: Right Hand
- Maximum Enclosure Height: Less than 30 inches
- Compatible With: 1494F, 1494D Disconnect Switches
- Weight: Approximately 2.2–3.2 lbs (varies by configuration)
- Standards/Certifications: UL, CSA, CUL, KC
- Included Components: Handle, Cam, Defeater Actuator Lever, Rollers, Shims
Typical Applications
- Industrial control enclosures and disconnect switch installations
- Electrical panels requiring NEMA 12 rated hardware
- OEM equipment integration for motor control centers
- Retrofit installations on existing 1494F/1494D disconnect switches
- Commercial and industrial facility electrical rooms
Compatibility & Replacements
The 1494F-L1 is a direct fit for Allen-Bradley 1494F and 1494D flange-mounted and terminal-mounted disconnect switches. Related hardware kits in the 1494F series (such as 1494F-L2 and 1494F-L4) serve different enclosure heights and latching configurations. For larger enclosures (40–60 inches), the 1494V-L1 is the equivalent hardware kit. Always verify enclosure height and switch model before ordering to ensure proper fitment. Authorized distributors maintain stock for quick replacement or retrofit applications.
