Overview
The Allen-Bradley 1485P-P1E4-R5 is a sealed KwikLink micro connector engineered for reliable DeviceNet field connections. Rated at 24 Volt DC and 3 Amp, this female micro connector provides secure termination for proximity sensors, limit switches, photoelectric sensors, and other industrial input/output devices. The sealed Valox housing protects against moisture and contaminants in harsh manufacturing environments.
Key Features
- Sealed Valox housing protects against moisture and environmental contamination
- Physically keyed design prevents incorrect wiring connections
- Female micro connector configuration for DeviceNet field wiring
- KwikLink heavy-duty construction for reliable, long-term performance
- 1 Port, Standard configuration for single-device connections
- Insulation displacement connector technology enables fast, tool-free wire termination
Technical Specifications
- Model: 1485P-P1E4-R5
- Connector Type: Female Micro, Sealed
- Rated Voltage: 24 Volt DC
- Rated Current: 3 Amp
- Housing Material: Valox
- Ports: 1 Port, Standard
- Weight: 0.26 lbs
- Design: KwikLink Heavy Duty
- Termination: Insulation Displacement
Typical Applications
The Allen-Bradley 1485P-P1E4-R5 connector is ideal for:
- Proximity sensor field connections on DeviceNet networks
- Limit switch terminations in automated assembly lines
- Photoelectric sensor connections in material handling systems
- Field-mounted I/O connections requiring sealed, weatherproof termination
- Mini-splitter and tee configurations for multi-sensor networks
Compatibility & Replacements
Compatible With
- Allen-Bradley DeviceNet networks and field devices
- Proximity sensors with KwikLink connectors
- Limit switches with micro connector interfaces
- Photoelectric sensors requiring sealed connections
- Allen-Bradley Bulletin 898N and 1485P mini splitters and tees
Replaces / Drop-In Replacement For
The 1485P-P1E4-R5 is the sealed Valox variant replacement for non-sealed or earlier-generation 1485P micro connector models. Verify compatibility with your specific sensor configuration and DeviceNet application before ordering.
Works With
- DeviceNet field communication protocol
- KwikLink connector ecosystem (male and female cord sets)
- Patchcord assemblies with male and female connectors
- Allen-Bradley mini-splitter and tee configurations
