Overview
The Acme Electric PL-112602 is a secondary fuse block kit engineered for industrial control transformers rated up to 1500 VA. Part of the TA series, this kit provides secondary circuit protection with dual-element slow-blow fuses designed to prevent nuisance trips while safeguarding transformer secondary windings and connected loads. Field-installable design allows fast, easy deployment in transformer maintenance and upgrades.
Key Features
- Dual-element slow-blow fuse design for reliable overload and short-circuit protection
- Rated for use with 1500 VA and lower industrial control transformers
- TA series configuration compatible with standard Acme transformer lineups
- Simple field installation with no special tools required
- NEC compliant (Article 450) fuse sizing guidelines included
Technical Specifications
- Manufacturer: Acme Electric
- Part Number: PL-112602
- Series: TA Secondary Fuse Block Kit
- Max Transformer Rating: 1500 VA
- Fuse Type: Dual-element slow-blow
- Fuse Class: CC (Cartridge Fuse)
- Installation: Field-mounted secondary fuse block
- Quantity in Kit: 4 fuses
- Compliance: NEC Article 450 compliant
Typical Applications
- Industrial control transformer secondary protection (12/24V, 115V outputs)
- HVAC and mechanical equipment control circuits
- Electrical machinery control systems requiring secondary-side fusing
- Replacement and maintenance of existing transformer installations
- OEM equipment requiring secondary circuit overcurrent protection
Compatibility & Replacements
Compatible With
- Acme Electric TA series industrial control transformers
- Transformers rated 1500 VA and below
- Systems using 12V, 24V, or 115V secondary outputs
- Primary voltages: 120V, 208V, 240V, 460V (50/60 Hz)
Replaces / Drop-In Replacement For
- Acme PL-112600 secondary fuse kit
- Acme PL-112601 secondary fuse kit
- Original equipment fuse blocks on Acme TA transformers
Works With
- Standard dual-element slow-blow fuses (Bussmann FNM, Littelfuse, Ferraz Shawmut types)
- Acme PL-112603 as compatible alternative per manufacturer specifications
- NEC-compliant electrical installations and maintenance protocols
