Overview
The 3M 23119301 is a 92VH vitrified grinding wheel engineered for precision and durability in conventional grinding applications. Built with a vitrified bond and advanced grain formulation, this 275×160×160 mm grinding wheel is designed to deliver high performance across a range of metalworking and manufacturing tasks. The 601W low-temperature bond delivers consistent results with minimal thermal distortion.
Key Features
- 92VH grain formula optimized for general-purpose grinding of tough metals
- Vitrified bond construction for superior strength and durability
- Low-temperature 601W bond reduces thermal stress during grinding operations
- Standard T1SP wheel design (Type 1, Straight, Plain) for conventional grinding machines
- Dimensions: 275 mm outer diameter × 160 mm width × 160 mm bore
- Resistant to chemical degradation and suitable for indefinite storage
Technical Specifications
- Wheel Designation: 92VH T1SP-275×160×160
- Grain Type: 92VH (multi-grit aluminum oxide blend)
- Bond System: Vitrified (low-temperature 601W)
- Wheel Shape: Type 1 Straight (T1SP)
- Outer Diameter: 275 mm
- Face Width: 160 mm
- Bore Diameter: 160 mm
- Abrasive Composition: White aluminum oxide, monocrystalline aluminum, crushed ceramic
- Part Number: 3M 23119301, J18VPLF29/601W
Typical Applications
The 3M 23119301 is well-suited for:
- Conventional generating and cylindrical grinding operations
- Surface finishing and precision grinding of ferrous and non-ferrous metals
- Tool and gauge grinding where consistent dimensional accuracy is required
- General-purpose grinding where versatility and durability are important
Compatibility & Replacements
Compatible With
- Standard grinders equipped for 160 mm bore wheels
- Conventional surface grinders and cylindrical grinders
- Systems requiring Type 1 straight wheel geometry
Replaces / Drop-In Replacement For
Verify compatibility with your grinding equipment before ordering. This wheel is designed to replace previous-generation 3M 92VH wheels of identical specifications (275×160×160 T1SP configuration).
Works With
- Standard grinding machine spindles with 160 mm bore capacity
- Wheel guards and flanges rated for 275 mm diameter wheels
- Coolant systems used in conventional grinding operations
- Spark erosion and conventional generating processes
