Overview
The Allen-Bradley 1485R-P2R5-C is a DeviceNet cordset that serves as a critical component in industrial communication networks. This unit features a 5-pin M12 micro female connector configuration with a 2-meter cable assembly. The 1485R-P2R5-C connects DeviceNet trunk lines to intelligent devices and modules, delivering deterministic real-time data exchange across PLC networks and distributed I/O systems.
Key Features
- 5-pin M12 micro female connector for DeviceNet trunk connections
- 2-meter cable length for flexible node placement
- Yellow CPE cable jacket rated for industrial environments
- Thin media DeviceNet physical layer
- Straight connector orientation for compact installations
- New in box condition with factory integrity
Technical Specifications
The 1485R-P2R5-C cordset is engineered to DeviceNet standards and integrates seamlessly into existing Rockwell Automation network architectures. Key specifications include:
- Cable Length: 2 meters
- Connector Type: M12 5-pin micro female
- Connector End: Straight (not angled)
- Cable Media: Thin media DeviceNet
- Jacket Material: Yellow CPE (chloroprene)
- Condition: New in box
- Standard: DeviceNet Physical Media IEC 61076-2-109
Typical Applications
- Connecting trunk line terminations to DeviceNet nodes
- Extending device connectivity in distributed I/O installations
- Assembly and food/beverage production line automation
- Packaging and material handling systems
- OEM machine builds requiring modular communication links
Compatibility & Replacements
Compatible With
- Allen-Bradley DeviceNet I/O modules and scanners
- Rockwell Automation CompactLogix and ControlLogix systems with DeviceNet adapters
- Third-party DeviceNet-compliant devices and master nodes
- DeviceNet trunk media and termination systems
Replaces / Drop-In Replacement For
- 1485R-P2R5-C (direct replacement)
- Verify compatibility with your system integrator before ordering for model-specific compatibility.
Works With
- DeviceNet Protocol and physical layer
- Allen-Bradley EtherNet/IP and legacy DeviceNet networks
- Studio 5000 programming software for network configuration
- RSLinx Classic and modern Rockwell Automation communication drivers
