Overview
The Whitman Controls P117G-10H-K12L72-X is a stainless steel miniature pressure switch designed for reliable performance in hundreds of industrial OEM and mechanical applications. This unit features a durable stainless steel construction, customer-adjustable set points, and industry-standard connectivity options that make it a versatile choice for pressure monitoring and control tasks.
Key Features
- Stainless steel body construction for corrosion resistance and durability
- Highly versatile—suitable for OEM and routine mechanical applications
- Customer-adjustable set points for flexible pressure range configuration
- Multiple connector options including TB, TS, Military, and DIN connectors
- Compact miniature form factor for space-constrained installations
Technical Specifications
- Sensor Code: -10H (100 PSIG maximum set point range)
- Pressure Range: 1 to 100 PSIG
- Electrical Rating: 1 Amp, 125 VAC
- Port Connection: 1/8″ NPT male thread
- Lead Length: 12 inches, insulated base
- Body Material: Stainless steel capsule (17-7 PH)
- Seal Material: Loctite #271
- Fitting Material: 303 stainless steel
- Set Point Configuration: Customer adjustable (factory set point N/A)
Typical Applications
- Machine tool hydraulic and pneumatic systems
- Industrial equipment pressure monitoring
- OEM equipment commissioning and replacement
- Routine mechanical pressure control in compact enclosures
- Laboratory and test stand applications requiring adjustable pressure thresholds
Compatibility & Replacements
Compatible With
- Standard 125 VAC control circuits
- Pneumatic and hydraulic systems rated 1–100 PSIG
- 1/8″ NPT threaded ports (male)
- Machine tool control and monitoring systems
- OEM assembly lines and equipment commissioning
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or equipment manufacturer before ordering, as replacement suitability depends on connector type and electrical circuit configuration. Whitman Controls manufactures OEM-specific replacements for various industrial equipment—contact the manufacturer for cross-reference assistance.
Works With
- TB, TS, Military, and DIN electrical connectors
- Standard industrial 125 VAC power circuits
- Pneumatic and hydraulic fluid systems
- Manual and automated pressure threshold monitoring
