Overview
The United Abrasives 24051 Type 1/Type 41 chop saw wheel is a fast-cutting, minimal-pressure abrasive designed for low-horsepower chop saw machines. Rated at 4,400 max RPM, this Iron Worker wheel excels at cutting structural metal applications with precision and speed. Proudly manufactured in the USA, the 24051 combines high-quality construction with proven performance in job shops, fabrication facilities, and metalworking environments.
Key Features
- Constructed using the highest quality fiberglass to withstand the toughest applications
- Fast cutting, specially formulated for use on low horsepower chop saw machines for fast cutting with minimal pressure
- Special ceramic aluminum oxide grain formula
- Type 1 wheel geometry—ideal for straight cutting on ferrous metals
- Excellent use on angle iron, channel iron, heavy rebar and other ferrous metals
Technical Specifications
Diameter: 14 inch, Thickness: 3/32 inch, Arbor: 1 inch. Material Application: Steel; Bond Type: Resin; Maximum Operating Speed: 4,400 RPM. Grit: 036 (36 grit).
Typical Applications
Fast cutting, minimal pressure wheel that is excellent for use on angle iron, channel iron, heavy rebar and other ferrous metals. Recommended for use on structural metal applications. These wheels are ideal for production cutting in fabrication shops, steel service centers, and general metal cutting environments where speed and precision matter.
Compatibility & Replacements
Compatible With
- Chop saw machines (low to medium horsepower)
- Abrasive cut-off saws rated for 14″ Type 1 wheels
- Bench and pedestal cutting equipment
- Industrial fabrication machinery compatible with 1″ arbor wheels
Replaces / Drop-In Replacement For
Verify with your equipment manufacturer or system integrator for specific interchangeable part numbers. The 24051 is a standard form factor (14″ x 3/32″ x 1″) and typically compatible with most commercial chop saws rated for Type 1 wheels.
Works With
- Chop saw machines with 1″ arbor spindles
- Low-horsepower abrasive cutting systems
- Structural metal cutting and fabrication workflows
