Overview
The TPC Wire & Cable 83340 is a 12-pole female single-ended cable assembly connector used in servo motor systems and motion control applications. This assembly provides a reliable interface for connecting servo drives to motors, encoders, and control systems in industrial automation environments.
Key Features
- 12-Pole Female Configuration: Standard single-ended connector design for servo and encoder applications.
- High-Flex Design: Supports continuous flexing and abrasion resistance in dynamic motion control environments.
- Shielded Construction: Tinned copper braid shielding reduces electromagnetic and radio frequency interference.
- Color-Coded Conductors: Alpha-numerically marked conductors for quick identification during assembly and troubleshooting.
- Industrial-Grade Materials: Oil-resistant insulation and finely-stranded copper conductors extend service life.
- UL/CSA Approved: Meets North American regulatory requirements for industrial cable assemblies.
Technical Specifications
- Model Number: 83340
- Connector Type: 12-Pole Female Single-Ended
- Voltage Rating: 600 V
- Maximum Conductor Temperature: 80°C
- Flame Rating: FT-1
- Operating Temperature Range: -40°C to +80°C
- Conductor Material: Finely-Stranded Tinned Copper
- Shielding: Tinned Copper Braid
- Insulation: Oil-Resistant Synthetic Polymer
- Certifications: UL Recognized (U.S. & Canada)
- Color: Orange (RAL 2003)
- Condition: New in Box
Typical Applications
- Servo motor power and feedback cable connections
- Allen-Bradley Kinetix servo drive systems
- Bosch Rexroth and Indramat drive systems
- Siemens, Lenze, and Mitsubishi motion control systems
- Factory automation and robotics applications
- Automotive assembly and packaging lines
- Food & beverage processing equipment
- Industrial machinery requiring continuous flex durability
Compatibility & Replacements
Compatible With
- Allen-Bradley / Rockwell Automation servo systems
- Bosch Rexroth Indramat drives
- Siemens motion control systems
- Mitsubishi servo drive systems
- Lenze and Kollmorgen drives
- General-purpose motion control applications with 12-pole connectors
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or controls engineer before ordering. The TPC Wire & Cable 83340 is engineered to replace OEM servo connectors and cables in systems utilizing 12-pole female single-ended interfaces. Consult your original equipment documentation or contact technical support for specific cross-reference information.
Works With
- TPC Trex-Onics® servo motor cable assemblies
- Industrial servo amplifiers and digital drives
- EtherNet/IP-enabled motion control systems
- PROFINET-based servo architectures
- Standard industrial automation control platforms
- Custom cable build and integration services
