Overview
The Telesis Pinstamp TMM5100 is a multiple-pin dot peen marking system designed for permanent product identification on metal and plastic surfaces. Hardened pins are pneumatically accelerated to create precise indent dot-matrix characters controlled entirely through software. The marking head manages X/Y axis motion to position the pin cartridge at exact coordinates, making it suitable for both automated production lines and handheld applications.
Key Features
- 6 independent pins for simultaneous marking—up to 6 characters per second
- Pneumatic pin drive system; no springs or electrical solenoids required
- Compact, lightweight design ideal for space-constrained or mobile setups
- Stores up to 400 marking patterns in controller memory
- Software-controlled dot size, density, location, and character shape
- Works with optional mounting post, hand crank, gimbal assemblies, and cable balancers
Technical Specifications
- Model: TMM5100
- Marking System Type: Multiple-pin dot peen (Pinstamp)
- Number of Pins: 6 (independent operation)
- Marking Speed: Up to 6 characters per second
- Pattern Storage: 400 patterns
- Pin Drive Method: Pneumatic (compressed air)
- Compatible Materials: Steel, aluminum, copper, stainless steel, titanium, plastic
- Control Interface: Pneumatic and electrical (via TMC420 or TMC470 controller)
- Mounting: Integration-ready; supports optional mounting posts and positioning fixtures
- Condition: Used, removed under working conditions
- Dimensions: Approximately 10″ W × 8″ H × 12″ D
- Weight: 11 lbs
Typical Applications
The TMM5100 is widely deployed in manufacturing environments for:
- Serial number and date code marking on industrial components and assemblies
- Part traceability in aerospace, automotive, and medical device production
- Barcode and 2D code generation for inventory and logistics tracking
- Permanent part identification on machined or cast metal parts
- Handheld or benchtop marking for low-volume custom jobs
- Integrated production-line marking in high-speed assembly operations
Compatibility & Replacements
Compatible With
- TMC420 Pinstamp Controller (standard electrical/pneumatic interface)
- TMC470 Pinstamp Controller (modern controller with serial, USB, and Ethernet ports)
- Merlin II Visual Design Software (pattern creation and management)
- Compressed air systems (6-pin simultaneous operation requires adequate air supply)
- Industrial marking cartridges and custom pin options for varying mark depth
Replaces / Drop-In Replacement For
The Telesis Pinstamp TMM5100 directly replaces other TMM5100 units in existing Pinstamp systems. Verify compatibility with your system integrator before ordering to confirm controller revision and cartridge options match your production requirements.
Works With
- Telesis Merlin II software platform for Windows-based pattern design
- Pneumatic control loops and solenoid valve systems
- Mounting posts with hand crank and precision cartridge standoffs
- Pistol grip handles with pushbutton control interfaces
- Barcode scanners and wands for automated part tracking integration
