The Telemecanique 2200EB220AA is a 2-pole IEC/NEMA contactor designed for reliable AC motor control in industrial applications. This used unit features an EB1 auxiliary relay and is rated for 25A inductive and 30A resistive loads at 600VAC maximum. With a 110-120VAC coil operating at 50/60 Hz, it delivers robust switching capability for medium-duty automation and process control systems.
Key Features
- 2-pole configuration for three-phase or dual-line motor circuits
- 25A inductive / 30A resistive current rating
- 600VAC maximum working voltage
- 110-120VAC coil supply (50/60 Hz)
- Integrated EB1 auxiliary relay for additional control logic
- 7-1/2 hp rated motor control capacity
- IEC 60947 and NEMA rated design
Technical Specifications
The 2200EB220AA combines proven Telemecanique (Schneider Electric) engineering for reliable contactor performance:
- Main Contacts: 2-pole design
- Load Rating (AC-3): 25A inductive @ 600VAC
- Load Rating (AC-1): 30A resistive
- Coil Voltage: 110-120V AC
- Coil Frequency: 50/60 Hz
- Maximum Operating Voltage: 600VAC
- Horsepower Rating: 7-1/2 hp
- Auxiliary Relay: EB1
- Mounting: DIN rail or panel-mount compatible
- Approximate Weight: 1 lbs
- Series: 2200EB
- Certifications: IEC 60947-4-1, NEMA C300
Typical Applications
The Telemecanique 2200EB220AA is suitable for:
- AC motor starting and stopping in HVAC systems
- Pump and compressor control circuits
- Industrial machinery and production line motor control
- Lighting load switching and distribution
- Process automation requiring EB1 auxiliary logic
- Replacement in legacy control panels
Compatibility & Replacements
Compatible With
- Standard 600VAC industrial power distribution systems
- 110-120VAC control transformer outputs (50/60 Hz)
- IEC 60947-4-1 compliant control circuits
- NEMA starter and contactor panels
- DIN rail and backplate mounting systems
Replaces / Drop-In Replacement For
- Original equipment manufacturer (OEM) Telemecanique 2200EB220AA units
- Equivalent Schneider Electric LC1-D09, LC1-D12 (verify coil voltage and contact rating)
- Legacy IEC 2-pole, 25A contactors with EB1 auxiliary relay requirements
Works With
- EB1 auxiliary relay modules and contact blocks
- Schneider Electric TeSys motor starters
- Standard 110-120V AC control wiring and PLCs
- Thermal overload relays rated for 25A coil circuits
- Industrial automation platforms requiring IEC contactor interfaces
