Overview
The Honeywell TC-CCN014 is a ControlNet interface module designed for integration into Honeywell distributed control system (DCS) architectures, including the C200 and C300 controller chassis. This module adheres to the ControlNet protocol, a high-speed deterministic network designed for real-time control applications that provides guaranteed data delivery within a specified time, critical for synchronized motion, interlocking, and process control. The TC-CCN014 serves as a communication gateway between the central controller and networked I/O modules, drives, and field devices across industrial plants.
Key Features
- Single media (twisted pair coaxial cable) ControlNet network connectivity
- Dual network ports with automatic failover and no communication loss on single link failure
- Manages scheduled and unscheduled data transfer, ensuring time-critical control data takes precedence
- Specifically engineered for direct integration into Honeywell C300 and C200 series controllers with streamlined configuration, diagnostics, and data mapping within the Experion PKS environment
- Wide operating temperature range (-40°C to +70°C) with strong resistance to vibration and shock, ensuring long-term reliability and minimal maintenance in harsh plant conditions
Technical Specifications
- Network Type: ControlNet (deterministic, real-time)
- Voltage Range: 24V DC (with redundant power input)
- Operating Temperature: 0°C to 60°C
- Mounting: DIN rail or panel mounting
- Dimensions: 5.5 inches (width) x 6.0 inches (height)
- Power Consumption: Approximately 5W
- Communication Protocol: Common Industrial Protocol (CIP) over ControlNet
- Interface: Dual redundant ControlNet ports
Typical Applications
The TC-CCN014 enables the central controller to communicate deterministically with I/O modules, motor drives, and smart field devices distributed throughout the plant, allowing the controller to receive real-time sensor readings and send commands to control devices with assured data delivery and precise timing. Common uses include:
- HVAC and building automation control networks
- Data center, industrial control systems, and telecommunication equipment
- Process automation and monitoring in chemical, oil & gas, and manufacturing facilities
- Legacy system integration and network gateway applications
Compatibility & Replacements
Compatible With
- Honeywell C200 and TDC3000 systems
- Honeywell C300 controller chassis
- Honeywell ControlEdgeâ„¢ and Experionâ„¢ systems
- ControlNet-based distributed I/O modules and devices
- Honeywell supervisory controllers (ACE)
Replaces / Drop-In Replacement For
Earlier CNI models TC-CCN013, TC-CCN012, TC-CCR013, TK-CCR013, TC-CCR012, and TK-CCR012 may be used but may not fully support the latest enhancements. The TC-CCN014 is the current standard interface module for single-media ControlNet connectivity in Honeywell C200/C300 chassis. Verify compatibility with your system integrator before ordering.
Works With
- Honeywell Experion PKS (Process Knowledge System)
- ControlNet protocol (CIP—Common Industrial Protocol)
- Industrial communication standards including Modbus, OPC, and other fieldbus protocols
- Honeywell ControlNet I/O modules (e.g., TC-IDJ161, TC-ODD321)
- Standard DIN-rail industrial control rack installations
