Overview
The Misumi SPEL-C16-80-P14-W7-KC90 is a precision punch pin with integrated locating dowel hole, designed for press die and mold component assemblies. This standard part supports accurate hole punching, drilling, and alignment in metal stamping and formation operations.
Key Features
- Integrated locating dowel hole for precision alignment
- Oblong shoulder design for secure press-fit installation
- Standard press die component from Misumi’s proven catalog
- Suitable for metal stamping, punching, and drilling applications
- Compatible with press die tooling systems
Technical Specifications
Part Number: SPEL-C16-80-P14-W7-KC90
- Designation: Oblong Shoulder Punch Pin
- Locating Feature: Dowel Hole
- Application: Press Die / Mold Components
- Manufacturer: Misumi
Typical Applications
This punch pin is commonly used in:
- Press die assemblies for metal stamping
- Injection mold tooling systems
- Precision punching and hole-forming operations
- Industrial mold and die manufacturing
- Tool stamping fixtures and assemblies
Compatibility & Replacements
Compatible With
- Misumi press die standard component systems
- Injection mold and plastic mold assemblies
- Precision punching and drilling fixtures
- Industrial stamping and forming equipment
Replaces / Drop-In Replacement For
Verify compatibility with your tool designer or system integrator before ordering. This is a standard catalog component; direct replacement models should be confirmed against your specific press die assembly documentation.
Works With
- Misumi SPEL series punch pin family
- Standard press die and mold component designs
- DIN and ISO compliant tooling systems
- Precision stamping and forming presses
