Overview
The SMC CDJ2B16-60-B is a compact double acting pneumatic cylinder from SMC’s CJ2 series. This unit combines reliable performance with clean room certification, making it suitable for precision automation applications requiring controlled linear motion. The 16mm bore and 60mm stroke design delivers consistent actuation in confined spaces where compact footprints are critical.
Key Features
- Double acting design for controlled extension and retraction
- Clean room grade construction to meet cleanroom facility standards
- 16mm bore diameter with 60mm stroke length
- Band mounting style for flexible installation options
- Integrated clevis mount type for direct mechanical attachment
- Compact CJ2 round body configuration
Technical Specifications
- Bore Size: 16 mm
- Stroke: 60 mm
- Operating Pressure: 0.7 MPa (101.5 psi)
- Cylinder Type: Double Acting, Single Rod
- Series: CJ2 Round Body
- Mounting Style: Band Mount
- Mount Type: Basic Integrated Clevis
- Certification: Clean Room Grade
- Condition: New in Box
Typical Applications
- Semiconductor and electronics manufacturing equipment
- Precision cleanroom automation systems
- Laboratory and medical device assembly
- Compact machine tool positioning and clamping
- Automated packaging and material handling in controlled environments
Compatibility & Replacements
Compatible With
- Standard pneumatic control systems with 0.7 MPa maximum operating pressure
- Cleanroom-certified facility air supply systems
- Direct valve interfaces supporting standard 5/2 and 3/2 directional control valve configurations
- M5 x 0.8 port thread fittings (standard SMC connector sizes)
Replaces / Drop-In Replacement For
- Older SMC CJ2 series single rod cylinders with identical bore and stroke specifications
- Verify compatibility with your system integrator before ordering to ensure mounting style and port orientation match your assembly
Works With
- SMC directional control valves (solenoid or manual pilot types)
- Standard pneumatic flow control regulators and lubricators
- 0.7 MPa pneumatic supply networks
- Band-mount and rod-end bracket accessories (sold separately)
- Auto switch mounting rails and solid state sensor systems (optional variants available)
