Overview
The SMC VQ1401N-51 is a premium 5 port solenoid valve from SMC’s VQ1000 series, engineered for high-speed, frequent operation in industrial pneumatic control systems. This plug-in style valve delivers stable response times and long service life, making it a trusted choice for OEMs and system integrators. The innovative mounting design allows field replacement without disassembling the entire manifold block, reducing downtime and labor costs.
Key Features
- 5 port solenoid valve with plug-in, base-mounted design
- Built-in one-touch fittings reduce piping time and installation labor
- Supports 2-position and 3-position actuator configurations
- Fast response times: 12 ms (metal seal), 15 ms (rubber seal) for 2-position operation
- Compact, space-saving profile with solenoid and fittings on single side
- Available with metal or rubber seal options for diverse fluid requirements
Technical Specifications
- Series: VQ1000 (VQ1401N)
- Port Configuration: 5 port
- Mounting Type: Base-mounted, plug-in
- Operating Pressure Range: 0.1 to 0.7 MPa (0.1 to 1.0 MPa high-pressure style)
- Coil Rated Voltage: 12 VDC, 24 VDC, 100 VAC, 110 VAC, 200 VAC, 220 VAC
- Ambient & Fluid Temperature: −10 to +50°C
- Fluid Medium: Air, inert gas
- Seal Type: Metal or rubber seal options available
- Response Time: 12 ms or less (2-position metal seal), 15 ms or less (2-position rubber seal)
Typical Applications
- Pneumatic control circuits requiring rapid switching and high cycle rates
- Manifold-integrated automation systems in manufacturing cells
- Pick-and-place, assembly, and material handling equipment
- Food and beverage processing with hygienic design requirements
- Machine tool control and precision positioning systems
Compatibility & Replacements
Compatible With
- SMC VQ1000 series manifold blocks and base units
- Pneumatic control systems using 2-position or 3-position directional control
- Industrial automation platforms requiring solenoid-operated directional control
- Systems with standard 24 VDC or 220 VAC power supply
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering for direct replacement applications.
Works With
- Pneumatic supply systems (compressed air, inert gases)
- SMC modular manifold connectors and fittings
- Industrial PLC and motion control systems
- Standard pneumatic piping and tube fittings (one-touch quick connects)
