Overview
The SMC NVFS2110-5D is a precision 24VDC solenoid pilot valve engineered for demanding pneumatic and hydraulic applications. Part of SMC’s VFS series of 5 port pilot solenoid valves with metal seals, this valve delivers reliable proportional control for system pressures up to 9.9 kgf/cm². The unit features base-mounted construction with manual override capability, making it suitable for integration into manifold systems across manufacturing, OEM, and process automation environments.
Key Features
- 5 port pilot solenoid valve with metal seals
- 24VDC solenoid coil for direct AC/DC control integration
- Base mounted manifold in plug-in and non plug-in styles
- Port sizes range from 1/8 to 3/4 with Rc(PT), NPTF and G(PF) thread types
- Manual override push-style control for emergency actuation
- Operating temperature range -10°C to +60°C for standard fluid/ambient conditions
Technical Specifications
- Solenoid Voltage: 24VDC
- Series: VFS2000
- Port Configuration: 5 port (4/5 port operation)
- Maximum Operating Pressure: 9.9 kgf/cm² (approx. 0.97 MPa)
- Seal Type: Metal seals (high durability, low leakage)
- Operating Temperature: -10°C to +60°C (fluid and ambient)
- Mounting Style: Base mounted
- Manual Override: Non-locking push style
- Thread Types Available: Rc(PT), NPTF, G(PF)
Typical Applications
- Pneumatic directional control in automated manufacturing systems
- Hydraulic pilot-stage actuation in multi-stage valve assemblies
- Process automation requiring precision flow direction switching
- OEM equipment for packaging, material handling, and assembly lines
- Manifold integration in custom hydraulic/pneumatic circuits
- Emergency manual override systems requiring low-power solenoid control
Compatibility & Replacements
Compatible With
- SMC base-mounted and body-ported manifold systems
- Standard pneumatic control circuits operating 24VDC solenoid valves
- Hydraulic pilot-operated directional control valve assemblies
- Industrial PLC and automation controller 24VDC output modules
- Standard 1/8″ to 3/4″ ported manifold blocks and sandwich plates
Replaces / Drop-In Replacement For
- NVFS2110-5DZ (latest generation equivalent)
- NVFS2110-5DC (non plug-in base mount variant)
- Other VFS2000 series solenoid valve configurations with 24VDC coils
Works With
- SMC pneumatic component ecosystems (filters, regulators, cylinders)
- Industrial hydraulic systems requiring solenoid-pilot actuation
- 24VDC control signal sources (relays, PLC outputs, motion controllers)
- Standard pneumatic/hydraulic manifold design software and CAD systems
- Proportional control electronics for modulated flow management
