Overview
The Sloan 180-1 XL Regal Flushometer is a manual, exposed diaphragm valve designed for commercial urinal applications. Regal® XL Flushometers provide water savings while maintaining performance advantages with accurate flush delivery, quiet performance and durable components. This unit delivers 1.0 gpf (3.8 Lpf) flush volume and meets ADA compliance and ASSE 1037 standards.
Key Features
- Diaphragm valve design with 25 – 100 PSI pressure rating
- ADA-compliant metal oscillating non-hold-open handle prevents urinal from exceeding intended flush volume
- Control stop plug and sweat solder adapter with cover tube
- Cast wall flange with set screw and vacuum breaker flush connection
- Low consumption flush accuracy controlled by Para-Floâ„¢ technology
- High copper, low zinc semi-red brass construction for dezincification resistance
Technical Specifications
- Flush Volume: 1.0 gpf (3.8 Lpf)
- Valve Type: Diaphragm
- Fixture Type: Urinal with top spud connection
- Spud Coupling: 1-1/4″ (32mm)
- Supply Pipe: 1″ (25mm)
- Rough-In Dimension: 11-1/2″ (292mm)
- Valve Body Material: Semi-red brass
- Finish: Polished chrome (CP)
- Pressure Rating: 25 – 100 PSI
- Handle Type: Metal oscillating non-hold-open
Typical Applications
Regal® XL Flushometers provide water savings while maintaining performance advantages in commercial and industrial restroom facilities. The unit is ideal for:
- Commercial office buildings and facilities
- Hospitality venues and public restrooms
- Healthcare and institutional facilities
- Educational institutions
- Industrial complexes requiring water conservation
Compatibility & Replacements
Compatible With
- Urinals with 1-1/4″ top spud connection
- 1″ I.P.S. water supply lines
- Commercial plumbing systems rated 25-100 PSI
- Sloan Bak-Chek® angle stop valves
Replaces / Drop-In Replacement For
- Sloan 180-1-XL-Regal (manufacturer number)
- Earlier Regal 180 series models with same spud configuration
Works With
- Sloan Bak-Chek® Control Stop valves
- Sloan Repair Kit No. A-36-A (for system service sink configurations)
- Standard 1-1/4″ FNPT spud couplings and wall flanges
- Sloan factory-authorized repair components and maintenance kits
