Overview
The Siemens 66.1031.098-01 line scan camera head with integrated Siemens 66.1031.051-01 module delivers precision imaging for high-speed industrial inspection and quality control. This CCD-based vision system is designed to work seamlessly within Siemens PLC environments, enabling real-time part inspection, defect detection, and process monitoring without additional vision processors. The combination of Dalsa’s proven line-scan optics with Siemens industrial automation integration reduces system complexity and accelerates deployment in manufacturing lines.
Key Features
- Dalsa HS-40-04K40 optical engine — High-resolution line scan sensor for detailed surface inspection and quality verification
- Direct PLC integration — Siemens module enables native connectivity to S7 processors and ET 200M I/O stations via standard communication
- CCD sensor technology — Proven reliability in continuous-duty manufacturing applications, superior low-light sensitivity
- Line scan architecture — Ideal for web inspection, edge detection, and continuous conveyor-based part verification
- Compact modular design — Camera head separates from control module for flexible mounting and cable routing in tight machine spaces
Technical Specifications
- Camera Model: Dalsa HS-40-04K40
- Sensor Type: CCD line scan
- Module Part Number: Siemens 66.1031.051-01
- Camera Head Part Number: 66.1031.098-01
- Country of Origin: United States
- Device Type: PLC I/O Module
- Condition: New in Box
- Primary Application: Industrial automation, quality control, surface inspection
Typical Applications
- Web/Film Inspection — Continuous surface scanning for defects, color consistency, and dimensional verification in paper, film, and textile production
- Edge and Seam Detection — Precise edge location for product positioning, gap verification, and automatic alignment in assembly lines
- Print Quality Verification — Line-by-line monitoring of print quality, registration, and ink coverage on packaging and labels
- Metal and Composite Surfaces — Scratch, dent, and surface finish inspection in automotive, aerospace, and metal processing
- Component Sorting and Grading — High-speed classification by visual features during pick-and-place and material handling operations
Compatibility & Replacements
The Siemens 66.1031.098-01 camera head pairs exclusively with the Siemens 66.1031.051-01 control module for full functionality. This assembly is compatible with Siemens S7-300, S7-400, and S7-1200 processors when integrated through ET 200M or equivalent I/O communication protocols. Drop-in replacement requires identical electrical and mechanical interfaces; verify module firmware revision before substitution. For legacy Dalsa line-scan systems or optical engine upgrades, consult the original equipment integrator or Siemens technical support to confirm mechanical mounting and software library compatibility.
