Overview
The Sick HTE18-V4A1BB infrared photoelectric sensor is part of Sick’s H18 SureSense family, engineered for flexible and reliable object detection across diverse industrial automation applications. This energetic-principle sensor combines infrared LED technology with an M18 hybrid housing design and potentiometer-based sensitivity adjustment, making it suitable for both basic and challenging detection scenarios including black, shiny, and varying-color objects.
Key Features
- Infrared LED light source (850 nm wavelength) for non-contact object detection
- M18 hybrid housing design with VISTAL plastic construction (higher durability than standard ABS)
- Energetic detection principle for versatile object recognition
- Potentiometer-based sensitivity and switching-point adjustment
- Signal strength light bar for intuitive setup and troubleshooting
- M12 4-pin male connector for plug-and-play integration
Technical Specifications
- Sensing Range: 5 mm to 1,000 mm (configurable based on object reflectivity)
- Light Source: Infrared LED, 850 nm wavelength
- Detection Principle: Energetic (diffuse mode)
- Housing: M18 hybrid, VISTAL plastic with PMMA optics
- Connection: M12 4-pin male connector
- Output Type: PNP/NPN switchable digital output (100 mA maximum)
- Switching Frequency: 1 kHz / 1,000 Hz capable
- Supply Voltage: 10 VDC to 30 VDC nominal (12 VDC / 24 VDC standard)
- Operating Temperature: −40°C to +70°C
- Ingress Protection: IP67 / IP69K
- Switching Mode: Light/dark switchable
- Housing Color: Blue
Typical Applications
- Packaging and labeling machinery detection
- Conveyor line object sensing and counting
- Parts presence/absence verification in assembly automation
- Transparent or highly reflective object detection
- Industrial automation positioning and synchronization
- Material handling and sorting systems
Compatibility & Replacements
Compatible With
- PLC and motion-control systems supporting 10–30 VDC inputs
- 24 VDC industrial automation control circuits
- M18-threaded mounting locations (24.1 mm to 25.4 mm head)
- M12 connector-based sensor networks
- Standard industrial control cabinets and DIN-rail power supplies
Replaces / Drop-In Replacement For
- HTE18-B4A1BB (H18 SureSense variant, same family)
- HTE18-P4A1BB (H18 SureSense variant, same family)
- Other Sick H18 SureSense M18 configurations with M12 connector
- Verify exact model interchangeability with your system integrator before ordering
Works With
- M18 sensor mounting hardware and brackets
- M12 A-coded 4-pin connector cables and patch cords
- PLC input modules accepting 24 VDC digital signals
- Industrial sensor networks requiring standard M12 connectivity
- Sick SureSense configuration and support tools
