Overview
The Shimaden SR24-1Y-9090 is a compact digital temperature controller from Shimaden’s trusted SR24 series. Built for industrial automation and process control, this microprocessor-based unit provides accurate temperature measurement and regulation using PID algorithm technology. The controller is engineered for reliability in harsh manufacturing and processing environments where precise thermal management is critical.
Key Features
- Microprocessor-based PID control algorithm for stable temperature regulation
- LED digital display for easy monitoring and programming
- Compact 96mm × 96mm panel-mount form factor
- Input flexibility with thermocouple or RTD sensor support
- Analog output capability for downstream control integration
- User-friendly interface for straightforward setup and operation
Technical Specifications
While exact specifications for the SR24-1Y-9090 variant are limited in available documentation, the SR24 series typically features the following characteristics:
- Control algorithm: PID with auto-tuning capability
- Display: LED readout with bright, clear visibility
- Input type: Thermocouple or RTD (model-dependent)
- Analog output: 4–20 mA standard
- Power supply: Typically 100–240 VAC
- Panel cutout: 96mm × 96mm
- Output: Relay or analog (model-dependent)
Typical Applications
- Plastic injection molding and extrusion temperature control
- Industrial oven and furnace regulation
- Heat-treat and annealing process management
- Food processing and packaging equipment
- Pharmaceutical and laboratory temperature maintenance
- General manufacturing process control
Compatibility & Replacements
Compatible With
- RTD sensors (PT100) for temperature measurement
- Thermocouple inputs (Type K, J, and others per configuration)
- 4–20 mA analog control loops
- Standard relay-based control circuits
- Industrial automation systems requiring PID feedback control
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The SR24-1Y-9090 may be compatible with other Shimaden SR24 variants (SR24-1Y models), but direct replacement eligibility depends on input type, output configuration, and control circuit requirements.
Works With
- RTD (Resistance Temperature Detector) thermometers
- Thermocouple sensors (standard types)
- Analog process control loops and data acquisition systems
- Legacy and modern industrial automation environments
- Manual and programmable logic controller (PLC) integration
