Schneider TeSys GV 54934-01 Auxiliary Contact Block for GV2/GV3 Breakers 1NO/1NC

Schneider TeSys GV 54934-01 Auxiliary Contact Block for GV2/GV3 Breakers 1NO/1NC

The Schneider TeSys GV 54934-01 Auxiliary Contact Block is designed to enhance the functionality of TeSys GV2 and GV3 motor circuit breakers. This auxiliary contact block provides one normally open (1NO) and one normally closed (1NC) contact, enabling efficient control and monitoring within industrial automation systems.

Key Features

• Versatile Contact Configuration: Offers both 1NO and 1NC instantaneous auxiliary contacts, facilitating diverse control logic applications.
• High Electrical Ratings: Supports operation up to 2A at 240V AC and 1A at 60V DC, ensuring reliable performance in various electrical environments.
• Front-Mounting Design: Easily installs on the front side of GV2 and GV3 circuit breakers, streamlining the assembly process without the need for additional tools.
• Secure Connections: Equipped with screw clamp terminals, providing robust and secure wiring connections.
• Durable Construction: Engineered for mechanical durability up to 100,000 cycles, ensuring long-term reliability in demanding industrial settings.
• Compliance and Certifications: Meets multiple international standards, including IEC, UL, CSA, CCC, and EAC, and is Green Premium compliant, adhering to RoHS and REACh environmental regulations.

Technical Specifications

• Rated Operational Voltage: 24 to 240V AC
• Rated Insulation Voltage: 300V (conforming to UL 508)
• Conventional Free Air Thermal Current (Ith): 2.5A
• Minimum Switching Current: 5 mA
• Minimum Switching Voltage: 17V
• Mounting Location: Front side of the circuit breaker
• Connection Type: Screw clamp terminals
• Dimensions: Height: 11 mm; Width: 45 mm; Depth: 29 mm
• Net Weight: 0.02 kg

The Schneider TeSys GV 54934-01 Auxiliary Contact Block is an essential component for enhancing the control capabilities of GV2 and GV3 motor circuit breakers, offering reliable performance and compliance with international standards for a wide range of industrial applications.
