<h2>Overview</h2>
<p>The <strong>Reliance 0-52824 current loop regulator</strong> is a precision analog control board engineered for Reliance Electric Maxpak DC drive systems. This CLRA (Current Loop Regulator Analog) module provides stable current loop regulation for motion control applications, enabling smooth and efficient operation of inductive motor loads across manufacturing, automotive, and industrial automation environments.</p>
<h2>Key Features</h2>
<ul>
<li>Integrated CLRA (Current Loop Regulator Analog) design for precise DC drive control</li>
<li>Over 25 integrated circuits including NAND gates, analog operational amplifiers, and XNOR gates</li>
<li>Dual rotary dials for rate and gain adjustment (0–10 range)</li>
<li>Three red LED status indicators for real-time circuit monitoring</li>
<li>Metal film resistors and ceramic/film capacitors for reliable long-term operation</li>
<li>Backplane connector and test point grid for easy troubleshooting</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Board Type:</strong> Current Loop Regulator (CLRA)</li>
<li><strong>Integrated Circuits:</strong> 25+ (NAND gates, op-amps, XNOR gates, transistors)</li>
<li><strong>Control Elements:</strong> 2 rotary dials, 2 set screws, 3 LED indicators</li>
<li><strong>Component Types:</strong> Metal film resistors, capacitors, transistors, backplane connector</li>
<li><strong>Dimensions (approx.):</strong> 10" length × 2" width × 12" depth</li>
<li><strong>Weight:</strong> 18 oz.</li>
<li><strong>Internal Code:</strong> 802286-16A</li>
</ul>
<h2>Typical Applications</h2>
<ul>
<li>DC motor speed and current regulation in Maxpak drive systems</li>
<li>Motion control and positioning systems in manufacturing</li>
<li>Automotive and aerospace production lines requiring analog feedback loops</li>
<li>Industrial automation retrofit and upgrade projects</li>
<li>System integration requiring tunable gain and rate adjustment</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Reliance Electric Maxpak DC drive systems (S6R MaxPak series)</li>
<li>Motion control and servo drive architectures</li>
<li>Analog feedback and closed-loop regulation systems</li>
<li>Standard backplane connector mounting interfaces</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>Reliance 0-52824 (all revisions)</li>
<li>Part number 052824 and O-52824</li>
<li>Internal reference 802286-16A</li>
</ul>
<h3>Works With</h3>
<ul>
<li>Maxpak DC drive control systems</li>
<li>Analog control loops and analog signal conditioning</li>
<li>Standard industrial automation repair and refurbishment workflows</li>
</ul>
