Overview
The R.T. Engineering PCM-050 current transducer is a specialized measurement device engineered for precise AC current monitoring in industrial electrical systems. The PCM-050 converts AC input current signals to proportional DC output, making it ideal for integration into control systems, data acquisition platforms, and instrumentation networks where accurate real-time current data is critical.
Key Features
- 50A input current capacity for standard industrial branch circuits
- Proportional DC output conversion for remote monitoring and control
- Compact integrated design combining transformer and transducer functions
- Galvanic isolation between primary and secondary circuits for safety and noise immunity
- Suitable for motor control, energy management, and process automation applications
Technical Specifications
The R.T. Engineering PCM-050 is engineered to operate within typical industrial parameters. For precise specifications including exact output range, frequency response, and power supply requirements, verify compatibility with your system integrator or contact the manufacturer directly.
Typical Applications
- Remote instrumentation and monitoring of electrical distribution systems
- Motor control circuits and soft-start integrations
- Energy management and power quality analysis
- Industrial automation control loops requiring current feedback
- Load profiling and demand-side management systems
Compatibility & Replacements
Compatible With
- Industrial automation controllers and PLCs
- Data acquisition systems and SCADA platforms
- Motor soft-starters and variable frequency drives (VFDs)
- Power quality analyzers and energy management systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The PCM-050 model designation is used by multiple manufacturers; confirm that this R.T. Engineering unit is compatible with your existing installation.
Works With
- 4-20 mA current loop systems
- Industrial 24 VDC power supplies
- Analog input modules on PLC platforms
- Standard industrial instrumentation networks
