Overview
The Hanwha QNO-6082R is a compact 2MP network IR bullet camera designed for outdoor surveillance and industrial monitoring. Part of Hanwha Vision’s Wisenet Q Series, this camera delivers 1920×1080 resolution at 30fps with triple codec support (H.265, H.264, MJPEG) and features a motorized 3.2–10mm varifocal lens for flexible field-of-view adjustment. The unit is rated IP66 and IK10, making it suitable for harsh environments with dust and moisture exposure. PoE or 12VDC powered, the QNO-6082R integrates seamlessly into ONVIF-compliant surveillance networks and includes edge storage via microSD card slot.
Key Features
- Motorized varifocal lens: 3.2–10mm (3.1x optical zoom) for remote zoom and focus adjustment
- Day/night IR imaging: 0.095 Lux color sensitivity; 0 Lux B/W with IR LEDs; 30m infrared viewing distance
- Multiple codec support: H.265, H.264, and MJPEG with simultaneous multi-stream delivery
- Smart analytics: Motion detection, tampering detection, defocus detection, directional/virtual line detection, hallway view (90°/270°)
- Rugged design: IP66 (dust and water jets), IK10 (vandal resistant); operating temperature –10°C to 50°C
- WiseStream II compression: Bandwidth-efficient encoding for network and storage optimization
- Edge storage: microSD/SDHC/SDXC slot supporting up to 128GB for local video retention
Technical Specifications
- Resolution: 2 Megapixel (1920 × 1080)
- Lens: 3.2–10mm motorized varifocal (F1.6–F3.4)
- Frame rate: 30fps at 2MP (H.265/H.264)
- Min. illumination: 0.095 Lux (color), 0 Lux (B/W with IR)
- IR LED range: Up to 30m
- Video compression: H.265, H.264, MJPEG
- Codecs: Triple codec with multiple streaming
- Day/Night: ICR (Infrared Cut-off filter) for automatic switching
- WDR: 120dB (extreme wide dynamic range)
- Storage: microSD/SDHC/SDXC up to 128GB
- Power: PoE (802.3af/at) or 12VDC
- Network protocols: IPv4, IPv6, TCP/IP, UDP/IP, RTP, RTSP, HTTP, HTTPS, DHCP, DNS, DDNS, NTP, FTP, SMTP
- Security: HTTPS login, digest authentication, IP filtering, 802.1X (EAP-TLS/LEAP)
- API: ONVIF Profile S/G/T; SUNAPI (Hanwha open platform)
- Weatherproof: IP66, IK10 rating
- Operating temperature: –10°C to 50°C (14°F to 122°F)
- Dimensions: 259.8mm × 83.2mm (Ø) (10.23″ × 3.28″)
- Weight: Approximately 500g (1.1 lbs)
- Certifications: CE, FCC/IC, VCCI, RCM, UKCA, NEMA 4X, IP66, IK10
Typical Applications
- Outdoor perimeter security: Building entrances, parking lots, fence lines
- Industrial facility monitoring: Loading docks, warehouses, manufacturing areas
- Transportation and logistics: Yard surveillance, vehicle inspection areas
- Infrastructure protection: Equipment enclosures, critical asset monitoring
- Access control zones: Gate entrances, employee areas, restricted zones
- 24/7 operations: Sites requiring reliable night vision and weather resistance
Compatibility & Replacements
Compatible With
- ONVIF Profile S, G, and T compliant VMS (Video Management Systems)
- Hanwha Wisenet Software and Wisenet Toolbox Plus
- Any network accessible via HTTP/HTTPS and RTSP protocols
- Standard 802.3af/at PoE infrastructure
- Genetec Stratocast-compatible systems
- Enterprise surveillance platforms supporting ONVIF
Replaces / Drop-In Replacement For
- QNO-6070R: Previous generation 2MP IR bullet camera with non-motorized lens
Works With
- Video Management Software: Hanwha Wisenet Pro, Wisenet Enterprise, third-party ONVIF-compliant NVRs and VMS platforms
- Communication protocols: RTSP, RTCP, HTTP, HTTPS, SSL/TLS, DHCP, DNS, DDNS, FTP, SMTP, SNMP (v1/v2c/v3)
- Streaming: Multiple simultaneous streams via H.265, H.264, or MJPEG
- Analytics integration: Directional detection, virtual line crossing, motion detection, tampering alerts, defocus notification
- Edge storage: Local recording via microSD card for failover and bandwidth reduction
