Overview
The PRX 9701 R6100328XXY1 is a single-phase rectifier diode manufactured by POWEREX for industrial power conversion and rectification. With a maximum continuous forward current of 300A and peak reverse voltage rating of 800V, this component is designed for demanding applications in industrial electrical equipment, DC power supplies, and motor drive systems. The stud mount design enables straightforward installation in heavy-duty industrial assemblies.
Key Features
- 300A maximum continuous forward current for high-power applications
- 800V peak reverse voltage rating
- Stud mount package for secure mechanical and electrical connection
- Single diode configuration for straightforward rectification circuits
- Rated for industrial and electrical equipment use
- Efficient power conversion with consistent performance characteristics
Technical Specifications
- Manufacturer: POWEREX
- Part Number: R6100328XXY1
- Product Series: PRX 9701
- Maximum Continuous Forward Current (If): 300A
- Peak Reverse Voltage (Vrrm): 800V
- Peak Surge Current: 300A
- Package Type: Stud Mount (DO-9)
- Diode Configuration: Single
- Technology: Silicon Rectifier
- Typical Applications: Industrial power supplies, motor drives, DC conversion
Typical Applications
The PRX 9701 R6100328XXY1 is well-suited for:
- Three-phase and single-phase power supply rectification
- Industrial DC motor drive systems
- Heavy-duty welding equipment and power conversion circuits
- AC-to-DC conversion in industrial electrical control panels
- High-current rectification in manufacturing and process automation equipment
Compatibility & Replacements
Compatible With
- Industrial power supply designs rated for 300A continuous load
- Three-phase and single-phase rectifier bridge circuits
- DC motor control and drive systems
- Heavy-duty electrical equipment requiring 800V reverse blocking
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Contact the manufacturer or your distributor for specific cross-reference information.
Works With
- Industrial power supply assemblies and rectifier modules
- Welding equipment rectifier circuits
- DC motor drive electronics
- Industrial automation and process control systems
