Overview
The Syntron POWERPULSE WT is a proven electronic feeder controller designed for industrial vibrating feeders and vibrators. This unit regulates the force output and vibration amplitude of 115V or 230V feeders through phase control delivered by a Silicon Controlled Rectifier (SCR) that converts AC power to DC. The POWERPULSE WT includes an adjustable voltage divider for precise control of both force and frequency, enabling fine-tuned material flow regulation in bulk material handling operations.
Key Features
- SCR Phase Control: Silicon Controlled Rectifier provides smooth, adjustable amplitude control for consistent feeder operation
- Type 4X Enclosure: Corrosion-resistant polycarbonate housing rated for indoor and outdoor use; water and dust tight
- Dual Voltage Options: Available for 115V and 230V, 50/60 Hz operation
- UL/CUL Certified: Meets electrical safety standards for industrial environments
- Compact Design: Small, lightweight form factor with simple installation; interchangeable with previous PowerPulse models
- Easy Operation: OFF-ON line switch with adjustable amplitude control; no complex programming required
Technical Specifications
- Input Voltage: 115V or 230V, 50/60 Hz (as specified on nameplate)
- Maximum Amperage: 5 amps
- Control Method: SCR phase control via adjustable voltage divider
- Enclosure Type: Type 4X polycarbonate, corrosion resistant
- Operating Environment: Indoor and outdoor rated
- Dimensions: 6.25″ L × 3.5″ W × 3.25″ H
- Safety Certifications: UL certified, CUL certified
- Country of Origin: Made in U.S.A.
Typical Applications
The POWERPULSE WT controller is ideal for bulk material handling systems including:
- Syntron vibrating feeders and vibrators
- Bin vibrator control in aggregate, mining, and chemical processing
- Material flow regulation in conveyor feed systems
- Electromagnetic vibrator force adjustment in manufacturing assembly lines
- Hopper and chute vibration control for material discharge optimization
Compatibility & Replacements
Compatible With
- Syntron Material Handling vibrating feeders (standard, electromagnetic designs)
- 115V/230V single-phase AC power sources, 50/60 Hz
- Bulk material handling and processing systems requiring variable amplitude control
- FMC Syntron legacy equipment and modern feeder systems
Replaces / Drop-In Replacement For
- Syntron POWERPULSE RC (formerly designated as PowerPulse RC)
- Model 7200-006-A (115/60V configuration)
- Model 225490-A (1-phase control, similar feature set)
Works With
- Syntron Material Handling feeder equipment
- Standard industrial electrical supply (115V or 230V, 50/60 Hz)
- Manual and automatic control signal integration for external sensing devices
- Multiple feeder configurations via control units designed for multi-unit applications
