Overview
Pomona 6244-48-2 is a professional-grade test lead assembly combining a minigrabber hook clip with a 4mm right-angle sheathed banana plug connector. The 6244-48-2 complies with IEC1010-2-31, the current international safety standard for test accessories. The 48-inch (1.22 m) cable delivers signal integrity for bench and field electrical testing across most modern multimeters.
Key Features
- Gold-plated beryllium copper hook in UL94V-0 fire-retardant nylon 6 body, accepting component leads up to 0.060″ (1.5 mm) O.D.
- 18 AWG silicone-insulated wire with integral one-piece molded design and double crimped connection for durability
- Nickel-plated brass body with nickel-plated beryllium copper spring and UL94V-2 fire-retardant insulation on banana plug
- Interfaces directly with multimeters configured for 4 mm sheathed safety jacks, including Amprobe, Fluke, H-P, Tektronix and Wavetek
- Slim 0.36″ (9.14 mm) grabber width for easier side-by-side stacking
Technical Specifications
The Pomona 6244-48-2 delivers safe, reliable performance across standard benchtop testing environments:
- Voltage Rating: 300 V (AC & DC)
- Current Rating: 5 A
- Cable Length: 48″ (1.22 m)
- Connector A: Minigrabber Hook Clip
- Connector B: 4 mm Right-Angle Banana Plug, Shrouded
- Wire Gauge: 18 AWG
- Insulation: Silicone (cable), Polypropylene (plug)
- Hook Material: Gold-Plated Beryllium Copper
- Safety Category: CAT II
- Color: Red
- Series: Pomona 6244
Typical Applications
The Pomona 6244-48-2 is ideal for:
- Bench multimeter testing and troubleshooting
- Component-level voltage and continuity measurements
- Service and field electrical diagnostics
- Test labs and training facilities
- Electronics repair and maintenance
Compatibility & Replacements
Compatible With
- Fluke multimeters (all 4 mm sheathed jack models)
- Amprobe multimeters
- Hewlett-Packard (H-P) multimeters
- Tektronix multimeters
- Wavetek multimeters
- Any DMM or test instrument with 4 mm sheathed safety jacks
Replaces / Drop-In Replacement For
The Pomona 6244-48-2 serves as a direct replacement for older or worn Pomona 6244 series red test leads with identical connector types and electrical ratings. Verify connector type and length before ordering to ensure compatibility with your specific test setup.
Works With
- IEC 61010-2-31 compliant test instruments
- CAT II rated measurement systems
- All standard 4 mm banana plug-receptacle jacks
- Laboratory and field test platforms
