Overview
The Parker PGI AK-022-C0 is a professional-grade stabilized connector flange kit engineered for demanding hydraulic and pneumatic applications. This kit provides reliable pressure stabilization and vibration damping in high-pressure fluid systems, ensuring consistent performance and extended component life. Built with 316 stainless steel construction, the AK-022-C0 delivers corrosion resistance and durability in harsh industrial environments.
Key Features
- 316 stainless steel (ASTM A743-316) stabilizing connector for corrosion resistance
- Teflon® flange seals for reliable pressure containment and leak prevention
- Stabilizing hex nut (1-1/2″, 300 Series SS) with 80–100 ft./lbs. torque specification
- Precision mounting bolt (7/16-20 x 1″ LG, ASTM 449-Type 1) for secure installation
- Dielectric isolation option available to prevent galvanic corrosion
Technical Specifications
- Maximum Pressure: 10,000 PSI @ 200°F; 8,000 PSI @ 450°F
- Material: 316 Stainless Steel (ASTM A743-316)
- Flange Seal: Teflon®
- Mounting Bolt: 7/16-20 x 1″ LG (ASTM 449-Type 1)
- Hex Nut Torque: 80–100 ft./lbs.
- Weight: Approximately 4.6–4.9 lbs per unit
- Standards Compliance: NACE MR0175/ISO 15156-3
Typical Applications
- High-pressure hydraulic manifold systems and test equipment
- Pneumatic and compressed gas delivery systems
- Industrial pump and valve installations
- Transducer and pressure sensor mounting
- Subsea and offshore drilling equipment (with NACE-compliant 316 SS option)
- Process automation and fluid power control systems
Compatibility & Replacements
Compatible With
- Parker hydraulic and pneumatic manifold systems
- Standard SAE-flange (NG6, NG10) valve bodies
- High-pressure test equipment and transducer blocks
- Industrial pump assemblies rated for 10,000 PSI operation
- Fluid power systems requiring ISO 15156-3 NACE compliance
Replaces / Drop-In Replacement For
- Parker PGI AK-022-C0-MN (standard carbon steel bolt version)
- Parker PGI AK-022-C0-MNW9 (stainless steel variant)
- Parker PGI AK-022LDV-C0-MN (short-length, vertical-only, dielectric isolation version)
Works With
- Parker manifold design software and engineering specifications
- ISO 4401 (CETOP 05) cavity standard valve bodies
- SAE J518 cavity standards (NG6, NG10, NG16 size manifolds)
- Standard pneumatic and hydraulic hose assembly fittings
- Pressure transducers and sensor port adapters
